Juniper QFX10002-60C-DC | QFX10002-60C 60-Port 100G Switch, 4x 1600W DC PSU

Authorised Juniper Partner

SKU:QFX10002-60C-DC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Juniper QFX10002-60C-DC is a 2U fixed-configuration data centre Ethernet switch with 60 QSFP28 100GbE ports, which can also run as 40GbE or 10GbE, and four 1600 W DC power supplies. Built on Juniper's custom Q5 ASICs, it delivers up to 12 Tbps of system throughput and 4 Bpps of forwarding capacity for spine, aggregation and high-density 100G deployments.

This is the DC-powered variant of the QFX10002-60C, suited to facilities with -48 V DC power plant. It includes hot-swappable redundant power supplies and three fan modules with front-to-back airflow, along with 24 GB of total packet buffer for demanding data centre workloads.

Features

- Built on Juniper custom Q5 ASICs
- Supports 100GbE, 40GbE and 10GbE port speeds in a 2U fixed form factor
- Hot-swappable redundant power supplies and fan modules
- Up to 1,024 BGP neighbors (Premium Feature License)
- DC-powered variant for DC power environments

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 60 x 100GbE QSFP28 ports (or 60 x 40GbE QSFP+, or up to 192 x 10GbE SFP+ via breakout)
- System throughput up to 12 Tbps
- Forwarding capacity up to 4 Bpps
- 24 GB total packet buffer
- 4 x 1600 W DC power supplies, 4 power cables
- 3 hot-swappable fan modules with redundant fans, front-to-back airflow
- 2U form factor
- Maximum power draw 2,500 W (8,530 BTU/hr)
- Up to 192 LAGs with 64 members per LAG
- 192,000 VOQs per PFE
- 2.5 GHz quad-core Intel CPU

FAQs

Q: What port speeds does the QFX10002-60C-DC support?
A: It has 60 QSFP28 ports that run at 100GbE, can operate as 40GbE QSFP+ ports, and can break out to as many as 192 x 10GbE SFP+ connections.

Q: How does the QFX10002-60C-DC differ from the QFX10002-60C?
A: The two share the same switching platform. The DC model ships with four 1600 W DC power supplies, while the QFX10002-60C uses AC power supplies.

Q: Does the switch have redundant power and cooling?
A: Yes. It has four hot-swappable 1600 W DC power supplies and three hot-swappable fan modules with redundant fans and front-to-back airflow.

Q: What is the switching performance?
A: The system delivers up to 12 Tbps of throughput and up to 4 Bpps of forwarding capacity, with 24 GB of total packet buffer.

Q: What form factor is it and how much power can it draw?
A: It is a 2U fixed-configuration chassis with a maximum power draw of 2,500 W (8,530 BTU/hr).

Q: Is a licence needed for large BGP deployments?
A: Support for up to 1,024 BGP neighbors requires the Premium Feature License.
