• Juniper QFX10002-36Q gray server rack with blue accents and hardware slots
1 1

Juniper

Juniper QFX10002-36Q | QFX10002 36-Port 40G QSFP+ Switch, 12x 100G QSFP28, AC

Juniper QFX10002-36Q | QFX10002 36-Port 40G QSFP+ Switch, 12x 100G QSFP28, AC

Authorised Juniper Partner

QFX10002-36Q

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Juniper QFX10002-36Q is a 2U fixed-configuration data centre spine and core Ethernet switch offering 36 x 40GbE QSFP+ ports or 12 x 100GbE QSFP28 ports, with up to 144 x 10GbE SFP+ ports available via breakout. Built on Juniper's Q5 ASIC with deep buffers, it delivers up to 2.88 Tbps of system throughput and up to 1 Bpps of forwarding capacity in a single platform.

This AC-powered variant ships with two redundant 1600 W power supplies and three fan trays for resilient operation. With 12 GB of packet buffer, latency as low as 2.5 microseconds within a PFE, and support for 10GbE, 40GbE and 100GbE interfaces on the same chassis, it suits data centre fabric leaf and spine deployments.

Features

- Custom Juniper Q5 ASIC with deep buffers
- 10GbE, 40GbE and 100GbE interfaces on the same platform
- Redundant power supplies and fan trays
- Precision Time Protocol (PTP) support
- Suited to data centre fabric leaf and spine use cases

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 36 x 40GbE QSFP+ ports or 12 x 100GbE QSFP28 ports
- Up to 144 x 10GbE SFP+ ports via breakout
- System throughput up to 2.88 Tbps
- Forwarding capacity up to 1 Bpps
- 2 x 1600 W AC power supplies, redundant
- 3 x fan trays
- 2U rack-mountable, 44.2 x 8.8 x 78.7 cm, approx. 23 kg
- Intel quad-core 2.5 GHz CPU with 16 GB SDRAM
- 12 GB total packet buffer using Hybrid Memory Cube, 100 ms per port
- Latency as low as 2.5 microseconds within a PFE, 5.5 microseconds across PFEs
- Maximum power draw 800 W, typical 560 W
- FIB up to 2 million entries (IPv4/IPv6), RIB 10 million (IPv4)

FAQs

Q: How many ports does the QFX10002-36Q provide?
A: It provides 36 x 40GbE QSFP+ ports, or 12 x 100GbE QSFP28 ports, with up to 144 x 10GbE SFP+ ports available via breakout.

Q: Does this model include power supplies?
A: Yes. It ships with two redundant 1600 W AC power supplies and three fan trays.

Q: What is the rack space requirement?
A: It is a 2U rack-mountable switch measuring 44.2 x 8.8 x 78.7 cm and weighing approximately 23 kg.

Q: What switching performance does it offer?
A: System throughput is up to 2.88 Tbps with forwarding capacity up to 1 Bpps, backed by 12 GB of deep packet buffer.

Q: Where is the QFX10002-36Q typically deployed?
A: It is designed as a data centre spine or core switch and is also suited to leaf and spine fabric deployments needing mixed 10G, 40G and 100G connectivity.

Q: Does it support Precision Time Protocol?
A: Yes, the QFX10002-36Q supports Precision Time Protocol (PTP).
