Juniper JPSU-650W-AC-AFO | EX4550 650W AC Power Supply, Front-to-Back Airflow (AFO)

Name: Juniper JPSU-650W-AC-AFO | EX4550 650W AC Power Supply, Front-to-Back Airflow (AFO)
Brand: Juniper
SKU: JPSU-650W-AC-AFO
Price: 1194.39 AUD
Availability: BackOrder

Authorised Juniper Partner

SKU:JPSU-650W-AC-AFO

Stock Status: Enquire

$1,194.39 inc. GST

$1,085.81 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Juniper JPSU-650W-AC-AFO is a 650W AC power supply for Juniper EX4550 Ethernet switches, built with front-to-back (AFO) airflow. Air enters through the front port side and exhausts through the rear FRU side, making it a fit for hot-aisle and cold-aisle data centre deployments. It is a hot-insertable, hot-removable field-replaceable unit that can be installed or swapped without powering down the switch.

The power supply accepts both low-line (100-120 VAC) and high-line (200-240 VAC) input at 50-60 Hz and delivers 650W in either case. Two power supply slots support redundant, load-sharing operation, and status LEDs report AC input, DC output and fault conditions. It is intended for EX4550-32F-AFO and EX4550-32T-AFO chassis fitted with AIR OUT (AFO) fan modules.

Features

- Hot-swappable without powering off the switch or disrupting switching
- Redundant, load-sharing operation with a second power supply
- Supports both low-line and high-line AC input
- Front-to-back airflow suited to hot-aisle and cold-aisle data centre deployments
- Status LEDs for AC input, DC output and fault indication

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 650W AC output power
- AC input range 100-120 VAC (low line) and 200-240 VAC (high line)
- AC input frequency 50-60 Hz
- AC input current 7.8 A (low line) / 3.8 A (high line)
- Front-to-back (AFO) airflow
- Hot-insertable and hot-removable FRU
- C13 power cord coupler per IEC 60320, country-specific cord supplied
- Status LEDs: AC OK, DC OK, Fault
- Weight 2.4 lb (1.1 kg)
- Compatible with EX4550-32F-AFO and EX4550-32T-AFO chassis

FAQs

Q: Which Juniper switches is the JPSU-650W-AC-AFO compatible with?
A: It is designed for the Juniper EX4550-32F-AFO and EX4550-32T-AFO chassis. The fan modules in the chassis must be AIR OUT (AFO) labelled.

Q: What does AFO mean on this power supply?
A: AFO denotes front-to-back airflow. Air is drawn in through the front port side and exhausted through the rear FRU side of the chassis.

Q: Can I hot-swap this power supply?
A: Yes. It is a hot-insertable, hot-removable field-replaceable unit, so it can be replaced without powering off the switch or disrupting switching.

Q: What AC input voltages does it accept?
A: It accepts 100-120 VAC (low line) and 200-240 VAC (high line) at 50-60 Hz, and delivers 650W on either input.

Q: Can I mix AC and DC power supplies or AFI and AFO components in one chassis?
A: No. Mixing AC and DC power supplies, or AFI and AFO components, in the same chassis is not supported.

Q: Does the EX4550 support power supply redundancy?
A: Yes. The chassis has two power supply slots that operate in a redundant, load-sharing configuration.
