• Juniper EX4650-48Y-AFO switch rear with gray rack, black ports, lights
1 1

Juniper

Juniper EX4650-48Y-AFO | EX4650 48x 25G SFP28 Switch, 8x 100G QSFP28, AC, AFO

Juniper EX4650-48Y-AFO | EX4650 48x 25G SFP28 Switch, 8x 100G QSFP28, AC, AFO

Authorised Juniper Partner

EX4650-48Y-AFO

In stock:5

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The EX4650-48Y-AFO is a 1U Layer 2/Layer 3 25GbE data centre switch from the Juniper EX4650 range, with 48 SFP28 ports and 8 QSFP28 100GbE uplinks. It suits top-of-rack, campus aggregation and service-provider deployments, and runs Junos OS. This variant has AC power supplies and AFO airflow (port side intake, PSU side exhaust), so it fits racks where cold air is drawn in from the port side.

Each SFP28 port runs at 25GbE, 10GbE or 1GbE depending on the transceiver fitted, and the 100G uplinks support 40GbE or 100GbE optics, allowing mixed-speed environments to be consolidated on one platform. Redundant hot-swappable power supplies and fan modules support continuous operation in demanding data centre and campus aggregation roles.

Features

- 25-Gbps and 100-Gbps wire speeds in a compact 1U platform
- Supports mixed 1GbE, 10GbE, 25GbE, 40GbE and 100GbE environments
- Auto-channelization on the 100G uplink ports
- Redundant, hot-swappable AC power supplies and fan modules
- Suited to data centre top-of-rack, enterprise campus distribution and service-provider aggregation

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 48 x 25G SFP28 ports (25GbE, 10GbE or 1GbE depending on transceiver)
- 8 x 100G QSFP28 uplink ports (40GbE or 100GbE depending on optics)
- 56 ports in total in a 1U fixed form factor
- Five fan modules with AFO airflow (port side intake, PSU side exhaust)
- Two 650 W AC power supplies in 1+1 redundancy
- Runs Junos OS with Layer 2 and Layer 3 support

FAQs

Q: Does the EX4650-48Y-AFO support PoE?
A: No. This is a 25GbE SFP28 data centre switch and does not provide Power over Ethernet.

Q: What does AFO airflow mean on this model?
A: AFO means air flows in from the port side and exhausts at the PSU side. Make sure this matches the hot and cold aisle layout of your rack before ordering.

Q: What speeds do the 48 SFP28 ports support?
A: Each port runs at 25GbE, 10GbE or 1GbE depending on the transceiver installed.

Q: What uplink options are available?
A: The 8 QSFP28 ports support 100GbE or 40GbE optics, and auto-channelization is supported on the 100G uplink ports.

Q: Is the power supply redundant?
A: Yes. The switch uses two 650 W AC power supplies in 1+1 redundancy, and the power supplies and fan modules are hot-swappable.

Q: Which operating system does it run?
A: It runs Junos OS with Layer 2 and Layer 3 support.
