Fortinet FS-AXF2430-PSD06 | FS-AX3660S Hot-swap DC Power Supply, Front-to-Back

Fortinet FS-AXF2430-PSD06 | FS-AX3660S Hot-swap DC Power Supply, Front-to-Back

Authorised Fortinet Partner

FS-AXF2430-PSD06

Stock Status: Enquire

$1,840.83 inc. GST
$1,673.48 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FS-AXF2430-PSD06 is a hot-swappable DC power supply module for the FortiSwitch FS-AX3660S series. It uses front intake and rear exhaust (front-to-back) airflow, making it suited to DC-powered telecom and data centre racks where cold-aisle-to-hot-aisle airflow is required.

Because the module is hot-swappable, it can be replaced without powering down the switch, and it supports redundant power supply configurations in the FS-AX3660S chassis. For front-to-back airflow it is used together with the FS-AXF2430-FAN04 fan unit. A grounding cable and DC connector are included; a power cable is not included and should be selected per the manufacturer-defined specifications.

Features

- Hot-swappable, so it can be replaced without powering down the switch
- DC-powered option for telecom and DC environments
- Supports redundant power supply configurations in the FS-AX3660S chassis
- Front-to-back airflow when paired with FS-AXF2430-FAN04

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Type: Hot-swappable DC power supply unit
- Airflow: Front intake, rear exhaust (front-to-back)
- Compatible series: FortiSwitch FS-AX3660S
- Companion fan unit (front-to-back): FS-AXF2430-FAN04
- Included accessories: Grounding cable, DC connector
- Power cable: Not included (use cable per manufacturer-defined specifications)

FAQs

Q: Which switches is the FS-AXF2430-PSD06 compatible with?
A: It is designed for the FortiSwitch FS-AX3660S series.

Q: Is this an AC or DC power supply?
A: It is a DC power supply unit, intended for DC-powered environments such as telecom racks.

Q: What airflow direction does it support?
A: Front intake and rear exhaust (front-to-back). For front-to-back airflow it is used with the FS-AXF2430-FAN04 fan unit.

Q: Can it be replaced while the switch is running?
A: Yes. The module is hot-swappable, so it can be replaced without powering down the switch.

Q: Does it include a power cable?
A: No power cable is included. A grounding cable and DC connector are supplied, and the power cable should be selected per the manufacturer-defined specifications.

Q: Can I run two power supplies for redundancy?
A: Yes. The FS-AX3660S chassis supports redundant power supply configurations.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
