Aruba R4H02A | 518 AP-518 Wi-Fi 6 Hardened Access Point, 6x RP-SMA, RW

Name: Aruba R4H02A | 518 AP-518 Wi-Fi 6 Hardened Access Point, 6x RP-SMA, RW
Brand: Aruba
SKU: R4H02A
Price: 1958.6 AUD
Availability: BackOrder

Authorised Aruba Partner

SKU:R4H02A

Stock Status: Enquire

$1,958.60 inc. GST

$1,780.55 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Aruba AP-518 (RW) is a hardened Wi-Fi 6 (802.11ax) indoor access point built for harsh, weather-protected environments such as warehouses and industrial freezers. It delivers dual-radio 4x4:4 MU-MIMO on 5 GHz and 2x2:2 on 2.4 GHz, with six external RP-SMA connectors so you can match antennas to the coverage pattern you need. This RW (Rest of World) regulatory domain variant is supplied for deployments outside the Americas and Japan.

Two Ethernet ports, including a 2.5GBASE-T uplink, let the AP-518 carry multi-gigabit Wi-Fi 6 traffic back to the network, and it is powered over 802.3at PoE+. Integrated Bluetooth 5 and a USB interface extend its use to location services and IoT. It supports both ArubaOS and Instant OS management, and its -40 to 55 degrees C operating range suits cold-storage and industrial sites.

Features

- Uplink and downlink OFDMA for efficient use of airtime
- Downlink MU-MIMO to serve multiple clients at once
- Target Wake Time (TWT) to improve battery life of IoT devices
- ClientMatch for optimised client steering
- Integrated Bluetooth for location services
- Cellular co-location support
- Up to 160 MHz channels and 4 spatial streams
- Wi-Fi CERTIFIED 6, WPA2/WPA3 security
- Beamforming, STBC, LDPC and CDD/CSD support

Warranty

Aruba Networking offers a Limited Lifetime Warranty on many of its hardware products, including select switches and access points. This warranty covers defects in materials and workmanship for the duration of the product's life, with support available for up to five years after the product's end-of-sale date.
Other Aruba products come with warranties ranging from 1 to 5 years, depending on the specific model. Warranty terms can vary based on the product category and model number.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Aruba Networking products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.hpe.com/psnow/doc/a00143138enw?jumpid=in_pdfviewer-psnow

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Wi-Fi 6 (802.11ax) dual radio: 5 GHz 4x4:4 MIMO and 2.4 GHz 2x2:2 MIMO
- Up to 4.8 Gbps (5 GHz, HE160) and 574 Mbps (2.4 GHz) maximum data rates
- 6 x RP-SMA connectors for external antennas (4 for 5 GHz, 2 for 2.4 GHz)
- 1 x 10/100/1000BASE-T and 1 x 1000/2.5GBASE-T Ethernet (RJ-45) ports
- PoE powered (802.3at PoE+); max power consumption 32 W with dual PoE ports
- Integrated Bluetooth 5 and USB interface
- Operating temperature -40 to 55 degrees C; UL2043 plenum rated
- Dimensions approx. 220 x 220 x 75 mm; weight 1.5 kg
- Region variant: RW (Rest of World)
- Supports ArubaOS and Instant OS

FAQs

Q: Does the Aruba AP-518 include antennas?
A: No. The AP-518 is a connectorized access point with six RP-SMA connectors, so external antennas are selected separately to suit the environment.

Q: How many antenna connectors serve each radio?
A: Four RP-SMA connectors serve the 5 GHz radio (4x4:4) and two serve the 2.4 GHz radio (2x2:2).

Q: How is the AP-518 powered?
A: It is powered over Ethernet using 802.3at PoE+. Maximum power consumption is 32 W with dual PoE ports.

Q: What does the RW designation mean?
A: RW stands for Rest of World, the regulatory domain this unit is configured for. It is the variant intended for deployments outside the Americas and Japan.

Q: What environments is the AP-518 designed for?
A: It is a hardened indoor access point for harsh, weather-protected locations such as warehouses and industrial freezers, with an operating range of -40 to 55 degrees C.

Q: Which management modes does the AP-518 support?
A: It supports both ArubaOS and Instant OS.
