Arista PWR-1011-AC-BLUE | 7280R3 1000W AC Power Supply, Reverse Airflow
Arista PWR-1011-AC-BLUE | 7280R3 1000W AC Power Supply, Reverse Airflow
Authorised Arista Partner
SKU:PWR-1011-AC-BLUE
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The PWR-1011-AC-BLUE is a 1RU, 1000W AC input power supply module with reverse (rear-to-front) airflow for Arista 7280R3 Series data centre switch routers. The blue colour coding identifies the reverse airflow variant, and a 93% Platinum efficiency rating helps keep power draw and heat output down in dense racks.
It accepts a 100-240V AC, 50/60Hz input through an IEC 60320 C14 connector and is hot-swappable, so a failed unit can be replaced without taking the switch offline. Fitting two modules provides 1+1 redundancy. It is compatible with the 7280CR3-32P4, 7280CR3-32D4 and 7280CR3-36S platforms, including K and A variants.
Features
Features
- Hot-swappable for tool-free replacement without taking the switch offline
- 1+1 redundancy for continuous operation
- Platinum-level 93% efficiency
- Reverse (rear-to-front) airflow, colour-coded blue
- Wide-range 100-240V AC input
- Designed for Arista 7280R3 Series data centre switch routers
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Output power: 1000W
- Input voltage: 100-240V AC, 50/60Hz
- Typical input current: 12.0 - 6.0A
- Input connector: IEC 60320 C14
- Efficiency: 93% (Platinum)
- Form factor: 1RU, 73.5mm
- Airflow: Reverse (rear to front), blue-coded
- Redundancy: 1+1 with two hot-swap power supplies per switch
- Operating temperature: 0 to 40 C (32 to 104 F)
- Storage temperature: -40 to 70 C (-40 to 158 F)
- Relative humidity: 5 to 95%
- Operating altitude: 0 to 3,000 m (10,000 ft)
FAQs
Q: Which Arista switches is the PWR-1011-AC-BLUE compatible with?
A: It is designed for the Arista 7280R3 Series, including the 7280CR3-32P4, 7280CR3-32D4 and 7280CR3-36S platforms and their K and A variants.
Q: What airflow direction does this power supply have?
A: It is the reverse airflow (rear-to-front) variant, identified by blue colour coding. Match the airflow direction of the power supplies and fans to your rack's hot and cold aisle layout.
Q: Is this power supply hot-swappable?
A: Yes. It can be replaced while the switch remains powered, and two modules provide 1+1 redundancy.
Q: What AC input does it require?
A: It accepts 100-240V AC at 50/60Hz through an IEC 60320 C14 input connector.
Q: What is the output power and efficiency?
A: It delivers 1000W and has a 93% Platinum efficiency rating.
Q: Can I mix airflow directions in the same switch?
A: No. Fit matching power supplies and fans with the same airflow direction in a switch so cooling works as designed.
