Arista

Arista CCS-722XPM-48ZY8-F | 722XPM 48-Port 2.5G 60W PoE Switch, 8x25G SFP28, MACsec, AC

Arista CCS-722XPM-48ZY8-F | 722XPM 48-Port 2.5G 60W PoE Switch, 8x25G SFP28, MACsec, AC

Authorised Arista Partner

SKU:CCS-722XPM-48ZY8-F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista CCS-722XPM-48ZY8-F is a fixed-configuration 48-port 2.5G PoE campus access switch with 60W PoE on every multi-gigabit RJ45 port, 8x25G SFP28 uplinks, MACsec encryption and front-to-rear airflow with AC power. It suits high-density Wi-Fi 6E and Wi-Fi 7 access point deployments, IP cameras and other high-wattage PoE devices at the campus access layer.

With 256-bit MACsec on downlink and uplink ports, VXLAN routing and bridging, and EVPN control plane support, this Layer 3 managed switch secures traffic at the edge while integrating into Arista cognitive campus designs managed through CloudVision. It ships with a 1050W AC power supply, with dual PSU operation lifting available PoE power for fully loaded deployments.

Features

- AES static and dynamic MACsec with 802.1X encryption
- 802.1Q VLANs and IPv4/IPv6 VRFs
- VXLAN overlay with CVX and EVPN control plane
- VXLAN routing and bridging
- Rapid Spanning Tree (802.1w), MSTP (802.1s) and RPVST+
- Managed with Arista cognitive campus tools including CloudVision

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 48 x mGig (100M-2.5GbE) RJ45 ports with 60W PoE
- 8 x 25G SFP28 uplinks
- MACsec (256-bit) on downlink and uplink ports
- Switching capacity 640 Gbps, forwarding rate up to 952 Mpps
- Default power supply 1050W AC (also supports 650W, 2000W AC and 500W DC)
- Default available PoE power 916W with a single 1050W PSU, 1809W with dual 1050W PSUs
- System power draw 134W typical, 160W maximum
- Front-to-rear airflow
- Dimensions 44.5 x 4.4 x 42.0 cm (1RU), weight 7.5 kg
- Layer 3 managed

FAQs

Q: How many PoE ports does the CCS-722XPM-48ZY8-F have?
A: It has 48 multi-gigabit RJ45 ports (100M to 2.5GbE), each capable of delivering up to 60W PoE.

Q: What uplink options are available?
A: The switch provides 8 x 25G SFP28 uplink ports.

Q: Does this switch support MACsec encryption?
A: Yes. It supports 256-bit MACsec on both downlink and uplink ports, with static and dynamic AES and 802.1X key exchange.

Q: What power supply does it use?
A: This model ships with a 1050W AC power supply and front-to-rear airflow. It also supports 650W and 2000W AC and 500W DC supplies.

Q: How much PoE power is available?
A: With a single 1050W PSU, 916W of PoE power is available by default. Dual 1050W PSUs increase this to 1809W.

Q: Is this a Layer 3 switch?
A: Yes. It is a Layer 3 managed switch supporting VRFs, VXLAN routing and bridging, and an EVPN control plane.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
