Arista CCS-722XPM-48Y4-2R-C14 | 720XP 48-Port PoE Switch, 4x25G 4x10G SFP, MACsec, 2x PSU

Arista CCS-722XPM-48Y4-2R-C14 | 720XP 48-Port PoE Switch, 4x25G 4x10G SFP, MACsec, 2x PSU

Authorised Arista Partner

SKU:CCS-722XPM-48Y4-2R-C14

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista CCS-722XPM-48Y4-2R-C14 is a 1RU Cognitive Campus 48-port PoE access switch with 48 x 10M-1GbE RJ45 ports delivering 30W PoE each, plus 4 x 25G SFP and 4 x 10G SFP+ uplinks. This SKU ships with 2 x PSU, rear-to-front airflow and a C14 inlet, with 256-bit MACsec support on downlink and uplink ports for secure campus and branch access deployments.

It provides 376Gbps of switching bandwidth, 1+1 redundant hot-swap power supplies and three hot-swap field-replaceable fans for resilient operation. Cognitive PoE, VXLAN, IPv4/v6 VRF support and Latency Analyzer monitoring suit high-density wireless, IP camera and VoIP edge deployments. MACsec is licensed separately.

Features

- MACsec 256-bit AES static and dynamic encryption with 802.1x
- Cognitive PoE for mission-critical services
- 802.1Q VLANs, IPv4/v6 VRFs and VXLAN
- Latency Analyzer and microburst monitoring
- Hot-swap redundant power supplies and fans

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 48 x 10M-1GbE RJ45 PoE ports at 30W
- Uplinks: 4 x 25G SFP + 4 x 10G SFP+
- 376Gbps switching bandwidth
- MACsec (256-bit) on downlink and uplink ports, 50Gbps downlinks / 50Gbps uplinks MACsec performance (licensed separately)
- System power typical/max: 83W / 102W
- Default power supply 1050W AC, default available PoE power 967W
- Supported PSUs: 650W, 1050W, 2000W AC and 500W DC, 1+1 redundant
- Three hot-swap field-replaceable fans, rear-to-front airflow
- 1RU, 44.5 x 4.4 x 36.4 cm, 6.8 kg
- Operating temperature 0 to 40°C, humidity 5-90% non-condensing

FAQs

Q: How much PoE power does the Arista CCS-722XPM-48Y4-2R-C14 provide?
A: Each of the 48 RJ45 ports supports up to 30W PoE. The default 1050W AC power supply provides 967W of available PoE power.

Q: What uplink options does this switch have?
A: It has 4 x 25G SFP and 4 x 10G SFP+ uplink ports, allowing flexible high-speed connections to the aggregation or core layer.

Q: Does this model support MACsec?
A: Yes. It supports 256-bit MACsec on downlink and uplink ports, with static and dynamic encryption using 802.1x. MACsec is licensed separately.

Q: Is the power supply redundant?
A: Yes. This SKU includes 2 x PSU in a 1+1 redundant, hot-swap configuration, with a C14 inlet. Supported PSUs include 650W, 1050W and 2000W AC and 500W DC.

Q: What is the airflow direction?
A: This variant uses rear-to-front airflow, supported by three hot-swap field-replaceable fans.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
