Arista

Arista CCS-722XPM-48Y4-2F | 722XPM 48-Port PoE Switch, 4x25G SFP28, 4x10G, Dual AC

Arista CCS-722XPM-48Y4-2F | 722XPM 48-Port PoE Switch, 4x25G SFP28, 4x10G, Dual AC

Authorised Arista Partner

SKU:CCS-722XPM-48Y4-2F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista CCS-722XPM-48Y4-2F is a 1RU 48-port PoE campus access switch with 48 x 10M-1GbE RJ45 ports delivering up to 30W per port, plus 4 x 25G SFP28 and 4 x 10G SFP+ uplinks. Dual AC power supplies, front-to-rear airflow and 256-bit MACsec on all downlink and uplink ports make it well suited to secure, high-density campus access and leaf deployments.

With 376Gbps of switching bandwidth, 559 Mpps forwarding and a PoE budget of up to 1808.5W with both power supplies installed, it powers dense deployments of access points, IP phones and cameras. It runs Arista EOS with CloudVision integration, VXLAN/EVPN segmentation and cognitive flow tracking for streamlined operations and visibility.

Features

- 256-bit AES static and dynamic MACsec encryption on all access and uplink ports
- 802.3af/at PoE power services
- 802.1Q, VRF and VXLAN/EVPN segmentation
- Cognitive flow trackers for CloudVision, IPFIX and sFlow
- Arista EOS with eAPI, DirectFlow and SDN support
- IEEE 1588 PTP transparent and boundary clock
- Supports 1G, 10G and 25G pluggable optics and cables
- In-service maintenance and upgrades

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 48 x 10M-1GbE RJ45 PoE ports (up to 30W per port)
- Uplinks: 4 x 25G SFP28 + 4 x 10G SFP+
- 376Gbps switching bandwidth (2-way)
- 559 Mpps packet forwarding (2-way)
- PoE power budget: 968W (single PSU) / 1808.5W (dual PSU)
- Standard power supply: 1050W AC (supported PSUs: 650W, 1050W)
- Dual AC power supplies
- Front-to-rear airflow
- 256-bit MACsec on downlink and uplink ports
- 4MB packet buffer
- Dual-core x86 CPU, 4GB system memory, 8GB flash
- 1 USB port
- 1RU form factor

FAQs

Q: How many PoE ports does the CCS-722XPM-48Y4-2F have?
A: It has 48 x 10M-1GbE RJ45 ports, each capable of delivering up to 30W of PoE.

Q: What is the total PoE power budget?
A: The PoE budget is 968W with a single power supply and 1808.5W with both power supplies installed.

Q: What uplink options are available?
A: The switch provides 4 x 25G SFP28 and 4 x 10G SFP+ uplink ports, supporting 1G, 10G and 25G pluggable optics and cables.

Q: Does this model support MACsec encryption?
A: Yes. It supports 256-bit MACsec on both downlink and uplink ports.

Q: What airflow direction does this SKU use?
A: This SKU uses front-to-rear airflow and ships with dual AC power supplies.

Q: What operating system does it run?
A: It runs Arista EOS, with eAPI, DirectFlow and CloudVision integration.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
