Arista CCS-720XP-48Y6-F-NA | 720XP-48Y6 48-Port Gigabit PoE+ Switch, 6x 25G SFP, Front-Rear

Arista CCS-720XP-48Y6-F-NA | 720XP-48Y6 48-Port Gigabit PoE+ Switch, 6x 25G SFP, Front-Rear

Authorised Arista Partner

SKU:CCS-720XP-48Y6-F-NA

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista CCS-720XP-48Y6-F is a 1RU Layer 3 campus PoE access switch with 48 x 10/100M-1GbE RJ45 PoE ports (802.3af/at, up to 30W per port) and 6 x 1G/10G/25G SFP uplinks. It delivers 198 Gbps (396 Gbps FDX) of throughput and a 294 Mpps forwarding rate, with front-to-rear airflow to suit hot-aisle and cold-aisle wiring closet layouts.

This SKU ships without power supplies or fans, which are ordered separately. It takes 3 x FAN-7000-F fans in an N+1 redundant arrangement and up to two power supplies, with default available PoE power of 982W typical with a single 1050W PSU and up to 1,875W with dual PSUs. The 720XP series runs Arista EOS and forms part of the Cognitive Campus platform, with 25G uplinks to distribution or spine layers.

Features

- Arista EOS network operating system
- Cognitive Campus platform with non-blocking wire-speed switching
- N+1 redundant, field-replaceable fans
- Dual power supply support for PoE budget expansion
- Layer 3 campus access switching with 25G uplinks to distribution or spine

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 48 x 10/100M-1GbE RJ45 PoE ports (802.3af/at, up to 30W per port)
- 6 x 1G/10G/25G SFP uplink ports
- 198 Gbps (396 Gbps FDX) throughput
- 294 Mpps forwarding rate
- Latency (RJ-45): 1.2 microseconds
- Default available PoE power 982W typical / 957W minimum with 1 x 1050W PSU; up to 1,875W with dual PSUs
- Dual-core x86 CPU, 4GB RAM, 8GB flash, 8MB packet buffer
- System power 68W typical / 93W maximum (excluding PoE)
- 3 x FAN-7000-F fans (N+1 redundant), up to 2 power supplies
- 1 x 100M/1G management port, RS-232 console, USB port
- 1RU, 17.3 x 1.75 x 12.5 in (44.0 x 4.4 x 31.75 cm), 6.9 kg
- Front-to-rear airflow (PSU and fans ordered separately)

FAQs

Q: Does the CCS-720XP-48Y6-F include power supplies and fans?
A: No. This SKU is supplied without power supplies or fans, which must be ordered separately. It uses 3 x FAN-7000-F fans and up to two power supplies.

Q: What airflow direction does this switch use?
A: This model uses front-to-rear airflow. Power supplies and fans must match this airflow direction.

Q: What is the PoE budget?
A: With one 1050W PSU the default available PoE power is 982W typical (957W minimum). Fitting two power supplies raises the available PoE power to up to 1,875W.

Q: What uplink options does the switch provide?
A: It has 6 x 1G/10G/25G SFP ports, suitable for connecting to distribution or spine switches at up to 25G per port.

Q: What PoE standards and power per port are supported?
A: The 48 RJ45 ports support 802.3af and 802.3at PoE, delivering up to 30W per port.

Q: Is this a Layer 3 switch and which operating system does it run?
A: Yes, it is a Layer 3 campus access switch running the Arista EOS network operating system.
