Arista

Arista CCS-720XP-48TXH-2C-S# | 720XP 48-Port Multi-Rate PoE Switch, 4x25G, 2x100G

Arista CCS-720XP-48TXH-2C-S# | 720XP 48-Port Multi-Rate PoE Switch, 4x25G, 2x100G

CCS-720XP-48TXH-2C-S#

Stock Status: Enquire

$0.00 AUD
$0.00 AUD
$0.00 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The Arista 720XP-48TXH-2C-S is a 1RU rack-mount campus PoE leaf switch delivering 48 x 100M–10G multi-rate RJ45 ports with up to 90W per-port PoE (802.3af/at/bt), 4 x 25G SFP28 and 2 x 100G QSFP uplinks. Designed for high-density enterprise campus and edge deployments, it supports a maximum PoE budget of up to 1775W and front-to-rear airflow, making it ideal for powering demanding endpoints such as Wi-Fi 6/6E access points, IP cameras, and VoIP handsets at scale.

Powered by Arista EOS and the CloudVision management platform, the 720XP-48TXH-2C-S delivers zero-touch provisioning, granular telemetry, EVPN VXLAN segmentation, and hardware-based VRF — bringing data centre-class automation to campus networks. Note: PSU and fans are required and sold separately (compatible PSU: PWR-1021-AC). Contact iptrading.com.au — your local source for enterprise-grade networking solutions.

Features

- Arista EOS® single-image operating system with cognitive campus network capabilities
- CloudVision management: automated provisioning, change control, telemetry, and analytics
- Zero-touch provisioning (ZTP) for rapid, hands-free deployment
- IEEE 802.1X and RADIUS authentication for secure access control
- TACACS+ authentication support
- 802.1Q VLAN and EVPN VXLAN network segmentation
- Wire-speed Layer 3 VRF segmentation
- Hardware-based VXLAN de-encapsulation for Wi-Fi traffic segmentation
- Enhanced Latency Analyzer (LANZ) for real-time performance monitoring
- Constant PoE power delivery with intelligent power prioritisation
- Platinum-rated PSU options for high energy efficiency
- Data centre-class virtualisation for large segmented campus networks
- Broad support for 1G, 10G, 25G, and 100G pluggable optics and cables

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 48 x 100M / 1G / 2.5G / 5G / 10G RJ45 PoE+ Ports (802.3af / at / bt, up to 90W per port)
- 4 x 25G SFP28 Uplink Ports
- 2 x 100G QSFP Uplink Ports
- Max PoE Power Budget: up to 1775W (with PWR-1021-AC PSU)
- Packet Buffer: 8 MB
- System Power Consumption: 168W / 199W (excluding PoE)
- Front-to-Rear Airflow
- 3 x Field-Replaceable Fans (sold separately)
- N+1 Redundant Power Supply Support
- Compatible PSUs: 650W, 1050W, or 2000W AC; 500W or 700W DC (sold separately)
- Operating Temperature: 0°C to 40°C
- Form Factor: 1RU, Rack-Mountable
- Warranty: 1-Year Limited Hardware Warranty

FAQs

Q: Does the Arista CCS-720XP-48TXH-2C-S ship with power supplies and fans included?
A: No — this switch ships without PSU or fans. Both are required for operation and must be purchased separately. The recommended PSU is the Arista PWR-1021-AC. Compatible options include 650W, 1050W, and 2000W AC units, as well as 500W and 700W DC units. Contact iptrading.com.au to bundle the correct accessories.

Q: What is the maximum PoE power budget on the 720XP-48TXH-2C-S?
A: With an appropriate PSU such as the PWR-1021-AC, the switch supports a maximum PoE budget of up to 1775W across all 48 ports, with up to 90W per port (IEEE 802.3bt). This makes it ideal for powering high-wattage devices like Wi-Fi 6E access points, PTZ cameras, and PoE-powered displays.

Q: What uplink options does the 720XP-48TXH-2C-S support?
A: The switch provides 4 x 25G SFP28 and 2 x 100G QSFP uplink ports, offering high-bandwidth connectivity to distribution or core switches. It supports a wide range of Arista-compatible pluggable optics and DAC/AOC cables across 1G, 10G, 25G, and 100G speeds.

Q: How is the Arista 720XP managed?
A: The 720XP runs Arista EOS®, a single-image operating system with a consistent feature set across the portfolio. It integrates natively with Arista CloudVision for centralised management, zero-touch provisioning, automated change control, streaming telemetry, and network analytics — suitable for large enterprise campus environments.

Q: Is the 720XP-48TXH-2C-S suitable for enterprise campus deployments?
A: Yes. The 720XP Series is purpose-built for high-density campus edge and leaf deployments. Its multi-rate RJ45 ports (up to 10G per port), high per-port PoE wattage, EVPN VXLAN support, and VRF segmentation make it well-suited for organisations deploying dense wireless, video surveillance, or unified communications infrastructure.

Q: Can I purchase the Arista CCS-720XP-48TXH-2C-S in Australia?
A: Yes. iptrading.com.au is an Australian B2B IT hardware reseller stocking Arista switching solutions. Our team can assist with configuration advice, compatible PSU and fan selection, and volume pricing for enterprise deployments across Australia.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
