Arista CCS-720XP-24ZY4-F-NA | 720XP-24ZY4 24-Port mGig PoE Switch, 4x 25G SFP, 650W, NA

Arista CCS-720XP-24ZY4-F-NA | 720XP-24ZY4 24-Port mGig PoE Switch, 4x 25G SFP, 650W, NA

Authorised Arista Partner

SKU:CCS-720XP-24ZY4-F-NA

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista CCS-720XP-24ZY4-F-NA is a 24-port multi-gigabit PoE access switch from the Arista 720XP Series (Cognitive Campus PoE). It pairs 16 x 100M-2.5GbE and 8 x 100M-5GbE RJ45 PoE ports with four 25G SFP28 uplinks in a 1RU, half-depth chassis, and runs Arista EOS. This North America SKU ships with front-to-rear airflow and a single 650W AC power supply, giving a 509W PoE budget.

The 8 mGig ports deliver up to 60W each, with the other 16 delivering up to 30W (802.3af/at), making this switch well suited to powering Wi-Fi 6/6E access points and other high-power PoE devices. With 1120 Gbps of switching bandwidth, 268 Mpps forwarding, 4096 VLANs and VXLAN support, it brings data-centre-class virtualisation to the campus edge. It has two PSU slots and three fan modules, so you can add a second power supply for redundancy or a higher PoE budget.

Features

- Runs the same Arista EOS software as other Arista products, simplifying network administration
- Data-centre-class virtualisation with 4K 802.1Q VLANs, IPv4/v6 VRFs and VXLAN support
- Multi-gigabit PoE for Wi-Fi 6/6E access points and other high-power devices
- Modular SFP28 uplinks supporting 1G to 25G speeds
- Redundant, hot-swappable power supplies and fan modules

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 16 x mGig (100M-2.5GbE) RJ45 PoE ports, up to 30W each (802.3af/at)
- 8 x mGig (100M-5GbE) RJ45 PoE ports, up to 60W each
- 4 x 25G SFP28 uplinks
- 1120 Gbps switching bandwidth
- Forwarding rate: 268 Mpps
- Latency: 1.2 microseconds
- MAC address table: 112,000 entries
- Packet buffer: 6MB
- 4GB system memory, 4GB flash, dual-core x86 CPU
- 4096 VLANs
- PoE budget: 509W with a single 650W AC PSU, 1787W with dual 1050W AC PSUs
- Default PSU: 1 x PWR-621-AC-RED 650W AC (2 PSU slots), optional PWR-1021-AC-RED 1050W AC
- 3 x FAN-7000-F fan modules, front-to-rear airflow
- Management: 1x console RJ45, 1x 1GbE management RJ45, 1x USB
- Form factor: 1RU, half-depth (48.3 x 4.4 x 31.7 cm), 6.2 kg (13.6 lb)
- Power draw: 141W typical, 156W maximum

FAQs

Q: How much PoE power does the CCS-720XP-24ZY4-F-NA provide?
A: With the single included 650W AC power supply the PoE budget is 509W. Fitting dual 1050W AC power supplies raises the budget to 1787W.

Q: Which ports support higher PoE wattage?
A: The 8 x 100M-5GbE RJ45 ports deliver up to 60W each. The 16 x 100M-2.5GbE ports deliver up to 30W each (802.3af/at).

Q: What uplink options does this switch have?
A: It has four SFP28 ports supporting speeds from 1G to 25G, depending on the optic or cable fitted.

Q: Does it support a second power supply?
A: Yes. The chassis has two PSU slots. It ships with one PWR-621-AC-RED 650W AC unit, and the optional PWR-1021-AC-RED 1050W AC unit can be fitted for redundancy and a higher PoE budget.

Q: What airflow direction does this SKU use?
A: This SKU uses front-to-rear airflow, provided by three FAN-7000-F fan modules.

Q: What software does it run?
A: It runs Arista EOS, the same software used across Arista's switching portfolio.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
