• APC AP4424A Netshelter rack ATS rear view with ports and display
1 1

APC

APC AP4424A | NetShelter Rack Automatic Transfer Switch, 2U, 32A, 230V, 16 C13 + 2 C19

APC AP4424A | NetShelter Rack Automatic Transfer Switch, 2U, 32A, 230V, 16 C13 + 2 C19

Authorised APC Partner

AP4424A

In stock:13

$2,245.38 inc. GST
$2,041.25 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC NetShelter AP4424A is a single-phase 2U rack automatic transfer switch (ATS) rated at 32A, 230V and 7400VA. It gives single-corded IT equipment redundant power from two independent sources via dual IEC 309 inlets, and provides 16 x C13 and 2 x C19 outlets for servers, switches and storage in a data centre or edge rack.

The unit includes a field-replaceable Network Management Card 3 (NMC3) for remote management and monitoring, with built-in circuit breaker protection and a 10 ms transfer time. Up to 32 Rack ATS units can be connected and managed from a single IP address, and the unit supports temperature and humidity monitoring with an optional sensor.

Features

- Seamless switching between two power sources to protect single-corded equipment
- Field-replaceable NMC3 minimises downtime
- Remote management via Web UI, CLI, SNMP or EcoStruxure Expert
- Temperature and humidity monitoring with optional sensor
- Supports APC Wi-Fi USB device for cableless installation and setup
- Cyber-secure design for edge and data centre deployments

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

Manual

FAQs

APC Replacement Battery Finder

Technical Specifications

- Single phase, 2U rack mount
- Rated current: 32A
- Rated voltage: 230V, 50/60 Hz
- Load capacity: 7400VA
- Inputs: 2 x IEC 60309 32A 2P+E (dual input power cords)
- Outputs: 16 x IEC C13 and 2 x IEC C19
- Transfer time: 10 ms
- Built-in circuit breaker protection
- Network Management Card 3 (NMC3), field-replaceable
- Gigabit Ethernet support
- Connect and manage up to 32 Rack ATSs from one IP address

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: What does the AP4424A rack ATS do?
A: It switches between two independent power sources so that single-corded equipment, such as servers and network devices, keeps running if one source fails.

Q: What inputs and outputs does it have?
A: It has two IEC 60309 32A 2P+E inputs and provides 16 x IEC C13 and 2 x IEC C19 outlets.

Q: What is the load capacity?
A: The AP4424A is rated at 32A, 230V, 50/60 Hz, with a load capacity of 7400VA.

Q: How quickly does it transfer between power sources?
A: The transfer time is 10 ms.

Q: How is it managed remotely?
A: The field-replaceable NMC3 card supports management via Web UI, CLI, SNMP or EcoStruxure Expert, and up to 32 Rack ATS units can be managed from one IP address.

Q: Can it monitor environmental conditions?
A: Yes, it supports temperature and humidity monitoring when an optional sensor is connected.
