Allied Telesis AT-X240-52GHXM-40 | AT-X240 48-Port Multi-Gigabit PoE++ Layer 3 Switch, 4x SFP+

Allied Telesis AT-X240-52GHXM-40 | AT-X240 48-Port Multi-Gigabit PoE++ Layer 3 Switch, 4x SFP+

AT-X240-52GHXM-40

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Allied Telesis AT-X240-52GHXM-40 is a 48-port Multi-Gigabit Layer 3 Lite Managed Switch designed for high-density enterprise access deployments demanding PoE++ power delivery across 2.5G and 5G connections. Each of the 48 downlink ports supports speeds of 100M/1G/2.5G/5G with PoE++ (802.3bt), making it ideal for powering next-generation Wi-Fi 6/6E access points, IP cameras, and high-power IoT endpoints without separate injectors. Four SFP+ uplinks provide 10G fibre or DAC connectivity for clean aggregation into the core.

Built on Allied Telesis's proven AlliedWare Plus (AW+) operating system, the AT-X240 delivers Layer 3 Lite routing including static routes and RIP, alongside a full L2 feature set covering VLANs, RSTP, MSTP, IGMP snooping, and QoS. The switch ships with an Australian power cord, ready for immediate rack deployment in enterprise, education, and healthcare environments. Visit iptrading.com.au to secure your order — enterprise-grade hardware with expert support.

Features

- 48-port Multi-Gigabit (100M/1/2.5/5G) access with PoE++ (802.3bt, up to 90W/port) on every downlink
- 4x 10G SFP+ uplinks for fibre or DAC aggregation into core switches
- Layer 3 Lite routing: static routes and RIPv1/v2 for inter-VLAN traffic management
- AlliedWare Plus operating system — consistent CLI and feature set across Allied Telesis product family
- Full L2 feature set: 802.1Q VLANs, RSTP/MSTP, LACP (802.3ad), IGMP snooping
- Advanced QoS for prioritising voice, video, and mission-critical application traffic
- Comprehensive management via CLI, Web GUI, SNMP v1/v2c/v3, and RMON
- Includes Australian power cord — rack-ready out of the box

Warranty

Allied Telesis provides a structured hardware warranty for products purchased after January 1, 2024, through approved sources such as IP Trading. Warranty terms vary by product class and are valid for purchases made in Australia and other supported regions.
Warranty Coverage Options:
• 2-Year Warranty: Standard coverage for most entry-to-mid-tier Allied Telesis hardware.
• 5-Year Warranty: Applies to selected enterprise-grade models.
• Limited Lifetime Warranty: Offered on eligible products for the operational life of the unit, with support ending five (5) years after the product’s official End-of-Sale (EOS) date.
Extended Warranty Options:
IP Trading offers tailored extended coverage and support solutions for Allied Telesis products. Speak to our team to customise a warranty plan that suits your business requirements.
https://www.alliedtelesis.com/au/en/warranty-july-2024-onwards

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 48x 10/100M/1/2.5/5G Multi-Gigabit PoE++ (802.3bt) downlink ports
- 4x 10G SFP+ uplink ports
- PoE standard: IEEE 802.3bt (PoE++), up to 90W per port
- Layer 3 Lite managed (static routing, RIPv1/v2)
- Full Layer 2 feature set: VLANs, RSTP, MSTP, LACP, IGMP snooping
- Operating system: AlliedWare Plus (AW+)
- Management: CLI, Web GUI, SNMP, RMON
- Power input: AC mains, includes AU power cord
- Form factor: 1U rack-mount

FAQs

Q: How many ports support PoE++ and what is the maximum wattage per port?
A: All 48 downlink ports support IEEE 802.3bt PoE++, delivering up to 90W per port — sufficient for the most demanding powered devices including Wi-Fi 6/6E APs and pan-tilt-zoom IP cameras.

Q: What speeds do the downlink ports support?
A: Each downlink port is auto-negotiating Multi-Gigabit, supporting 100 Mbps, 1G, 2.5G, and 5G — enabling full-speed connections to modern Multi-Gigabit endpoints over existing Cat5e/Cat6 cabling.

Q: What Layer 3 routing capabilities does the AT-X240-52GHXM-40 provide?
A: The switch operates as a Layer 3 Lite device, supporting static routing and RIPv1/v2. For more advanced dynamic routing (OSPF, BGP), a full-L3 Allied Telesis switch in the X240 or X530 family would be required.

Q: Can I purchase the AT-X240-52GHXM-40 in Australia with local support?
A: Yes. IP Trading (iptrading.com.au) stocks Allied Telesis hardware in Australia and provides expert pre-sales and post-sales support. The unit ships with an Australian power cord, ready for immediate deployment.

Q: What SFP+ modules are compatible with the four uplink ports?
A: The four SFP+ ports accept standard 10G SFP+ transceivers including Allied Telesis-branded single-mode and multimode fibre modules, as well as 10G DAC (Direct Attach Copper) cables. Third-party transceivers may work but Allied Telesis branded optics are recommended for warranty compliance.

Q: Is this switch suitable for high-density Wi-Fi 6E deployments?
A: Yes. The combination of 48x Multi-Gigabit (up to 5G) PoE++ ports and 4x 10G SFP+ uplinks makes the AT-X240-52GHXM-40 purpose-built for dense Wi-Fi 6/6E access layer deployments where APs require both 2.5G+ throughput and high PoE wattage.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
