Arista DCS-7804R3-BND-DC-S2 | 7804R3 Modular Chassis Switch Bundle, 6x3kW DC PS, 6x FM-R3, 2x Sup

Authorised Arista Partner

SKU:DCS-7804R3-BND-DC-S2

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Arista 7804R3 modular chassis switch bundle is a 10 RU, 4-slot data centre switch router from the 7800R3 series, supplied as a factory bundle with 6x 3kW D2 DC power supplies, 6x 7804R3-FM fabric modules and 2x 7800-Sup1A supervisors (dual supervisor). It scales to 144 x 400G, 576 x 100G or 1152 x 50G ports and delivers up to 115 Tbps and 24 Bpps of throughput, and the extended rack kit is included.

The fully scheduled, cell-based lossless fabric uses virtual output queues, and supports any combination of 7800R3 line cards. Hot-swappable fabric modules, redundant 3000W DC power supplies and dual supervisors provide redundancy for the fabric, power and control plane, all running Arista EOS.

Features

- Fully scheduled, cell-based lossless fabric architecture with virtual output queues
- Active-active hot-swappable fabric modules with individually serviceable fans
- Redundant hot-swappable 3000W DC power supplies with 1+1 grid redundancy
- Dual supervisors for control plane redundancy, running Arista EOS
- Supports any combination of 7800R3 line cards, including 400G, 100G and 50G options
- Up to 24GB packet memory per line card for deep buffering
- Extended rack kit included

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Chassis: DCS-7804, 10 RU
- 4 line card slots
- 2 supervisor slots (2x 7800-Sup1A included)
- 6 fabric module slots (6x DCS-7804R3-FM included)
- 6x 3000W PWR-D2-3041-DC power supplies (-48 to -60VDC)
- Power supply input: 2x M6 studs, 70A max, 94% efficiency
- Power supply slots: 8 (24 kW maximum power budget)
- Maximum density: 144 x 400G, 576 x 100G or 1152 x 50G ports
- Maximum throughput: 115 Tbps / 24 Bpps
- Maximum power consumption: 9,121 W
- Supervisor: 7800-Sup1A with multi-core x86 CPU and 64GB DRAM
- Dimensions (H x W x D): 43.6 x 44.1 x 94 cm
- Weight: 74 kg chassis only, 203 kg full system
- Operating system: Arista EOS
- Extended rack kit included

FAQs

Q: What is included in the DCS-7804R3-BND-DC-S2 bundle?
A: The bundle includes the 7804 chassis, 6x 3kW D2 DC power supplies, 6x DCS-7804R3-FM fabric modules, 2x 7800-Sup1A supervisors and the extended rack kit. Line cards are not part of the bundle.

Q: Does this bundle use AC or DC power?
A: DC. The six PWR-D2-3041-DC power supplies each accept -48 to -60VDC input via two M6 studs and deliver 3000W of output.

Q: How many fabric modules does the chassis need?
A: Six fabric modules are required per chassis and all six are included. The fabric supports graceful degradation.

Q: Is the control plane redundant?
A: Yes. Two 7800-Sup1A supervisors are included, providing 1+1 supervisor redundancy.

Q: What port densities can the 7804R3 reach?
A: With line cards fitted, up to 144 x 400G, 576 x 100G or 1152 x 50G ports, with maximum throughput of 115 Tbps and 24 Bpps.

Q: What rack space does the chassis need?
A: The chassis is 10 RU. The extended rack kit is supplied, and a full system can weigh up to 203 kg.
