Check Point Firewall Sizing Guide 2026: Compare Models from SMB to Data Center

In an era where cyber threats evolve by the hour, your firewall shouldn't just be a gateway, it should be your most intelligent asset. Choosing the right Check Point appliance is a balancing act between uncompromising threat prevention and network fluidity.

At IP Trading, we specialise in the Check Point Quantum ecosystem. Whether you are deploying a single Spark appliance for a branch office or a Maestro Hyperscale cluster for a global data center, we help you secure the hardware that delivers the industry’s highest "catch rate" for zero-day attacks without sacrificing low-latency performance.

Why Check Point Quantum Force?

While other firewalls focus solely on throughput, Check Point focuses on Prevention-First security. With the 2026 lineup, Check Point has unified its architecture to offer:

• AI-Powered Threat Prevention: Powered by ThreatCloud AI, aggregating telemetry from millions of sensors globally to block 2 billion attacks per year.
• Maestro Hyperscale Ready: The only solution that allows you to stack up to 52 gateways together, giving you the flexibility to expand capacity on demand, much like adding more RAM to a computer.
• Unified Management: Manage on-prem, cloud, and IoT security from a single "SmartConsole" dashboard, reducing administrative overhead by up to 80%.
• Unmatched Value: With the new Quantum Force series, Check Point provides up to 3x higher threat prevention performance per rack unit compared to previous generations.

Use our 2026 sizing guide below to find the appliance that matches your required Threat Prevention (TP) throughput and port density.

SMB & Small Branch (Quantum Spark Series)

Models: 2530 / 2550 / 2570 / 2580

The 2500 series is the newest generation of Spark appliances, introducing Wi-Fi 7 and 5G connectivity to the SMB market. These desktop units are fanless, making them ideal for quiet office environments while delivering enterprise-grade AI threat prevention.

The Quantum Spark series is built specifically for small environments that need big-business security without the complexity. These are "all-in-one" devices that often replace several pieces of hardware.

• Best For: Retail stores, small offices, and distributed branch networks.
• Key Features: Integrated Wi-Fi 7 (on specific models), optional 5G failover for 100% uptime, and a compact desktop form factor that doesn't need a noisy server room.
• Performance: These models range from 750 Mbps to 3.25 Gbps in Threat Prevention throughput, ensuring your small office stays protected at high speeds.

Quantum Security Gateways: Performance + Hardware Overview
Spark (2530 / 2550 / 2560 / 2570 / 2580)

Scroll horizontally to compare models.

Looking for SMB Firewalls?

Explore the full Quantum Spark range designed for small offices and branch environments.

Growing Business & Branch Office

Models: 1535 - 1800 | 1900 / 2000

This category bridges the gap between small offices and mid-sized enterprises. The 1900 / 2000 series introduces a 1U rack-mount form factor with high port density for organisations that need to segment multiple departments.

• Best For: Medium-sized offices, multi-site businesses, and SMBs with heavy SaaS usage (Zoom, Teams, Salesforce).
• Key Features: 10GbE SFP+ uplinks, redundant power supplies (on 1900/2000), and integrated SD-WAN orchestration.
• Performance: Threat Prevention ranges from 440 Mbps (1535) up to 5 Gbps (2000).

1500 Series: Performance + Hardware Overview
(1535 / 1555 / 1575 / 1595 / 1600 / 1800)

Scroll horizontally to compare models.

¹ Includes Firewall, Application Control, URL Filtering, IPS, Antivirus, Anti-Bot, SandBlast Zero-Day Protection with logging.
² Includes Firewall, Application Control, IPS with logging.
³ Performance measured with default/maximum memory.
⁴ Figures measured with Smart Accel enabled. Smart Accel is available on release R81.10 and above. Smart Accel must be enabled on Web UI and is currently supported on devices managed via Web UI or SMP.

1900 / 2000: Performance + Hardware Overview

Scroll horizontally to compare models.

¹ Includes Firewall, Application Control, URL Filtering, IPS, Antivirus, Anti-Bot, SandBlast Zero-Day Protection with logging.
² Includes Firewall, Application Control, IPS with logging.
³ Performance measured with default/maximum memory.

Enterprise Edge & Campus

Models: 3920 / 3950 / 3970 / 3980 | 9100 / 9200 / 9300

The Quantum Force 3000 and 9000 series are designed for the modern campus. These units focus on high-speed connectivity and the ability to handle the massive concurrent session loads of a high-density user environment.

• Best For: Corporate campuses, educational institutions, and data-heavy perimeter security.
• Key Features: Modular I/O slots for 25GbE fiber, increased IPS throughput for internal segmentation, and "Plus/Max" configurations for memory expansion.
• Performance: The 9300 model delivers a robust 9 Gbps of Threat Prevention and up to 70 Gbps of raw firewall throughput.

3900 Series: Performance + Hardware Overview
(3920 / 3950 / 3970 / 3980)

Scroll horizontally to compare models.

Perimeter Gateways (9100 / 9200 / 9300): Performance + Base/Plus/Max Configurations

Scroll horizontally to compare models (and Base/Plus/Max configurations).

Base, Plus, Max: Base is a minimum hardware configuration. Plus includes redundant components, additional memory and network I/O (for less than purchasing these items separately). Max is the maximum capacity that the security appliance supports.
¹ Check Point proprietary blend which includes Firewall, Application Control, URL Filtering, IPS, Antivirus, Anti-Bot, SandBlast (incl. DNS Security & Zero Phishing).
² Check Point proprietary blend which includes Firewall, Application Control, IPS.
³ Performance measured with default/maximum memory.
⁴ Web mix is based on NetSecOpen Standard.
* Per Gateway.

Shop our Check Point enterprise firewalls.

High-Performance Enterprise

Models: 9400 / 9700 / 9800

These 1U appliances are built for "hyperefficient" security. They are optimised for the high volumes of encrypted traffic (TLS 1.3) that dominate modern enterprise networks without requiring a massive 2U or 3U footprint.

• Best For: Large enterprises, financial services, and healthcare networks requiring strict segmentation.
• Key Features: Support for 40/100GbE ports, ASIC-based firewall acceleration, and dual NVMe SSDs for high-speed logging.
• Performance: Reaches up to 20 Gbps of Threat Prevention and massive 185 Gbps firewall throughput on the 9800.

9400 / 9700 / 9800: Performance + Base/Plus/Max Configurations

Scroll horizontally to compare models and configurations.

Base, Plus, Max: Base is a minimum hardware configuration. Plus includes redundant components, additional memory and network I/O (for less than purchasing these items separately). Max is the maximum capacity that the security appliance supports.
¹ Check Point proprietary blend which includes Firewall, Application Control, URL Filtering, IPS, Antivirus, Anti-Bot, SandBlast (incl. DNS Security & Zero Phishing).
² Check Point proprietary blend which includes Firewall, Application Control, IPS.
³ Performance measured with default/maximum memory.
⁴ Web mix is based on NetSecOpen Standard.
* Per Gateway.

Large Enterprise & Data Center

Models: 7000 / 16000 / 26000 / 28000 (and Quantum Force 19000 / 29000)

These are the flagship platforms for mission-critical environments. They offer telco-grade reliability and are the primary engines for Check Point Maestro, allowing you to cluster multiple gateways into a single "hyperscale" system.

• Best For: Tier 1 enterprises, cloud providers, and data centers with high-throughput "east-west" traffic.
• Key Features: Hot-swappable redundant power and fans, up to 128 GB of RAM, and Maestro Hyperscale support for scaling up to 1.5 Tbps.
• Performance: Standalone units like the 28000 deliver 30 Gbps of Threat Prevention, while the newer 29200 Force model scales to 75 Gbps.

Large Enterprise / Data Center: Performance + Configurations
(7000 / 16200 / 16600 / 26000 / 28000 / 28600)

Scroll horizontally to compare models and Base/Plus/Max configurations.

Base, Plus, Max: Base is a minimum hardware configuration. Plus includes redundant components, additional memory and network I/O (for less than purchasing these items separately). Max is the maximum capacity that the security appliance supports.
* Concurrent Sessions shown as Base/Plus/Max where applicable (per the PDF).

Quantum Force Data Center: Performance + Configurations
(19100 / 19200 / 29100 / 29200)

Scroll horizontally to compare models and Base/Plus/Max configurations.

Base = minimum configuration. Plus includes additional memory & redundancy. Max = maximum supported hardware capacity.

Discover our Check Point Industrial firewall range

How to Choose Your Firewall (Sizing Tips)

When comparing Check Point models, don't just look at the "Firewall" speed. Consider these real-world factors:

1. Threat Prevention (TP) Throughput: This is your actual speed with security features like IPS and Anti-Bot active. Always size based on TP.
2. TLS/HTTPS Inspection: Over 90% of web traffic is encrypted. Inspecting it requires massive CPU power. If you have high encryption needs, move up one model tier.
3. Appliance Configurations:

• Base: Essential hardware for standard needs.
• Plus: Includes redundant power and extra memory.
• Max: The highest supported memory and expansion capacity for future-proofing.

If you’re unsure, our team can help you size the correct model based on your environment.
