How to Extend NBN Wi-Fi to a Shed or Outbuilding

The problem turns up on acreage blocks, hobby farms, and suburban properties with large backyards alike. You have a working NBN connection in the house. The shed, workshop, or outbuilding is somewhere out the back. And no matter what you try, you cannot get a reliable Wi-Fi signal out there.

Unlike Starlink, where the dish and router sit in one known location, NBN connections arrive at your property through a range of different technologies. FTTP, FTTN, HFC, FTTC, Fixed Wireless. Each one has a slightly different setup inside your home, and each one determines what you can and cannot connect to when extending your network to an outbuilding.

This guide covers the full picture: why standard solutions fail, how your specific NBN connection type affects your options, and how a point-to-point wireless bridge solves the problem regardless of which NBN technology you are on.

On Starlink rather than NBN? The solution is identical. See our guide on extending Starlink Wi-Fi to a shed for the Starlink-specific version of this article.

First: which NBN connection type do you have?

This matters because different NBN technologies deliver the connection to your home differently, which affects where you plug in a wireless bridge and what adapter or equipment you may need.

You can find your connection type in your NBN provider's app, by checking your physical NBN hardware, or by entering your street address into the official NBN Co Check Address tool. Here is what each type means for your setup:

Why Wi-Fi extenders and mesh systems do not work at this distance

Wi-Fi extenders and mesh nodes

A Wi-Fi extender needs to receive a usable signal from your router before it can rebroadcast it. On suburban blocks where the shed is 30 to 50 metres from the house, a well-placed extender can sometimes bridge the gap. Beyond that, particularly where there are metal shed walls, corrugated iron roofing, or fencing in the path, the signal degrades too quickly for an extender to work reliably.

Mesh systems are better than single extenders but face the same fundamental limit. Each node needs to be within reliable wireless range of the previous one, and the bandwidth available at each hop drops with distance and interference. A mesh node halfway across the backyard may improve things marginally, but it rarely solves the problem cleanly at distances over 80 to 100 metres.

Powerline adapters

Powerline adapters transmit network data through your home's electrical wiring. They are a practical solution in some indoor scenarios, but they have a specific limitation that makes them unsuitable for most shed setups in Australia.

Powerline adapters only work reliably when both units are on the same electrical phase and circuit. In most Australian properties, the house and an outbuilding are on separate electrical supplies. They may share the same meter or come from the same switchboard, but the physical wiring path between them is long enough that powerline performance drops significantly or fails entirely. Metal conduit between buildings also degrades the signal.

Underground ethernet cable

Burying ethernet cable is the most reliable wired option for short distances. CAT6 cable runs cleanly up to 100 metres without signal loss. For a shed that is 20 to 80 metres from the house on a suburban block, this is often the simplest and cheapest solution if you are willing to dig.

Beyond 100 metres, standard ethernet cable cannot carry the signal reliably without active equipment in between. The trenching also becomes expensive and disruptive on larger blocks, and the cable needs to be properly installed in conduit to protect it from ground moisture and mechanical damage over time.

For distances over 100 metres, or where trenching is impractical, a point-to-point wireless bridge is the clean solution. It creates a wireless link between the two buildings that behaves like an ethernet cable.

We recently completed this exact type of job for a rural property where the outbuilding was 500 metres from the main house. The same approach works equally well for suburban and peri-urban properties at shorter distances. The setup involves three Ubiquiti products working together.

1. Ubiquiti NanoBeam 5AC Gen2 x 2 (SKU: NBE-5AC-Gen2)

A point-to-point link needs two matched radios, one at each end. The NanoBeam 5AC Gen2 is a compact 5 GHz outdoor unit with a 19 dBi directional antenna built into the enclosure, which is what gives it the reach. You buy two: one for the house, one for the shed.

Each unit is small, light and simple to mount on a wall, pole or roof bracket. The antenna is integrated, so there is no separate dish to align, just the unit itself pointed at its partner.

• 5 GHz band operation: good range and less congestion than 2.4 GHz on suburban and acreage blocks
• 19 dBi integrated directional antenna
• Up to 450 Mbps throughput, which is well clear of what any NBN plan delivers
• Gigabit ethernet port on each unit
• Outdoor-rated enclosure with ball-joint mount for fine aiming
• PoE powered, with an adapter supplied in the box
• Configured through airOS, Ubiquiti's web interface for its outdoor wireless range


Setup is browser-based rather than pre-paired. You set one unit as the access point and the other as the station in airOS, aim them at each other, and the link establishes.

Product page: Ubiquiti NanoBeam 5AC Gen2 (order two for one link)

2. Ubiquiti UniFi U6+ Wi-Fi 6 Access Point (SKU: U6+)

The bridge delivers the connection to the shed, but that gives you a network port rather than Wi-Fi. To get Wi-Fi inside the building, you plug a Wi-Fi access point into the bridge's ethernet port.

We use the UniFi U6+ for this. It is a compact ceiling or wall mountable unit that delivers dual-band Wi-Fi 6 across the building. For a shed or workshop, one unit usually covers the whole space.

• Wi-Fi 6 (802.11ax): faster and more efficient than older Wi-Fi 5 hardware
• Dual-band: 2.4 GHz and 5 GHz, with up to 2402 Mbps on the 5 GHz radio
• Gigabit ethernet input from the bridge
• Compact ceiling or wall mount design
• Managed through the UniFi Network application, alongside any other UniFi hardware on site


Product page: Ubiquiti UniFi U6+

3. Ubiquiti U-POE+ Gigabit PoE Injector (SKU: U-POE+)

The U6+ access point is powered over ethernet. If there is no PoE switch at the shed, the U-POE+ injector powers it straight from a wall socket. It is a gigabit 802.3at injector with an AU plug, rated to 30W, which is comfortably more than the U6+ needs.

Product page: Ubiquiti U-POE+

How it connects to your NBN setup

The connection into the house-end bridge unit comes from a spare LAN port on your router. Refer to the connection type table earlier in this article for exactly which device your router plugs into for your NBN type. The bridge sits downstream of the router, the same way a wired computer or printer would.

Here is the full signal path:

1. NBN arrives at your home via your NTD, HFC box, NCD, or VDSL2 modem depending on connection type
2. Your router connects to the NBN device and distributes the connection inside the house
3. An ethernet cable runs from a spare LAN port on your router to the house-end bridge unit mounted outside
4. The bridge transmits wirelessly to the shed-end unit
5. The shed-end bridge outputs an ethernet connection inside the shed
6. The U6+ access point connects to that ethernet port and broadcasts Wi-Fi inside the shed
7. Devices in the shed connect to the U6+, on the same network as the house or a separate one

One important note for FTTN users: your modem-router integrates the modem and router into one device. The LAN ports on the back of that combined unit are where the bridge connects. There is no separate NBN box to deal with.

The one thing you must check: line of sight

A point-to-point bridge requires an unobstructed path between the two units. No buildings, no dense trees, no hills. The two units need to be able to see each other directly.

On suburban and peri-urban blocks this is usually straightforward since the buildings are on flat ground. Common obstructions to watch for include boundary fences with solid panels rather than open pickets, large established trees between the house and shed, or the shed being located behind a secondary structure.

Line of sight check: stand at the shed and look directly at the point on the house where the bridge unit would mount. If you can see it with nothing in the way, you have line of sight. If trees or a fence partially block the path, raise the mounting height on one or both ends. Even a metre of extra height on a roof mount can clear most suburban obstructions.
