• Moxa WiFi-BGN 802.11ac dual RF module kit black industrial switch front view
1 1

Moxa

Moxa WiFi-BGN | UC-8100 Dual-Band 802.11ac Wi-Fi Module Kit, SMA Leads

Moxa WiFi-BGN | UC-8100 Dual-Band 802.11ac Wi-Fi Module Kit, SMA Leads

Authorised Moxa Partner

WiFi-BGN

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa WiFi-BGN is a dual-band 802.11ac/a/b/g/n Wi-Fi module kit for Moxa UC-8100 series Arm-based computers. It installs in the Mini PCIe socket and adds 2.4 GHz and 5 GHz wireless connectivity, so UC-8100 computers can communicate with peripheral devices wirelessly.

The kit is supplied complete, with two i-PEX MHF to RP-SMA leads, an ANT-WDB-ARM-02 dual-band antenna and M2 mounting screws. This makes it a straightforward way to add Wi-Fi to a UC-8100 deployment without sourcing separate RF components.

Features

- Enables wireless communication between UC-8100 series computers and peripheral devices
- Dual-band 2.4 GHz / 5 GHz Wi-Fi operation
- Complete kit with module, RF leads, antenna and mounting screws

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 802.11ac/a/b/g/n Wi-Fi module x1
- i-PEX MHF male to RP-SMA female leads x2
- ANT-WDB-ARM-02 dual-band antenna x1
- M2 screws x2
- Operating frequency: 2.412 GHz to 2.472 GHz and 5.180 GHz to 5.825 GHz (subject to local regulations)
- Mini PCIe interface module for UC-8100 series computers

FAQs

Q: Which computers is the Moxa WiFi-BGN compatible with?
A: It is designed for Moxa UC-8100 series Arm-based computers and installs in the Mini PCIe socket.

Q: What is included in the kit?
A: The kit includes one 802.11ac/a/b/g/n Wi-Fi module, two i-PEX MHF to RP-SMA female leads, one ANT-WDB-ARM-02 dual-band antenna and two M2 screws.

Q: Which Wi-Fi standards and bands does it support?
A: It supports 802.11ac/a/b/g/n across the 2.4 GHz and 5 GHz bands.

Q: What frequency ranges does the module operate on?
A: It operates from 2.412 GHz to 2.472 GHz and from 5.180 GHz to 5.825 GHz, subject to local regulations.

Q: Do I need to buy an antenna separately?
A: No. An ANT-WDB-ARM-02 dual-band antenna and two RP-SMA leads are included in the kit.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
