Moxa V1200-WLAN22-AX | V1200 Wi-Fi 6 802.11ax Module Kit, 2x I-PEX to QMA Cables

Authorised Moxa Partner

SKU:V1200-WLAN22-AX

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The V1200-WLAN22-AX is a Wi-Fi 6 (802.11ax) module kit that adds wireless connectivity to Moxa V1200 Series Arm-based rail computers. It installs in the M.2 E-key slot and supports 802.11a/b/g/n/ac/ax across the 2.4 GHz and 5 GHz bands, making it suited to railway TCMS data acquisition and train-to-ground applications.

The kit includes two coaxial cables (I-PEX 4 MHF male to QMA female), a thermal pad and a heat sink, so everything needed to fit the module to a compatible V1200 host is supplied. V1200 models with cellular and Wi-Fi enabled are specified for operation from -40 to 70°C and are tested to EN 50155.

Features

- Adds Wi-Fi 6 wireless connectivity to V1200 Series rail computers
- Supplied with coaxial cables, thermal pad and heat sink for installation
- Supports 802.11a/b/g/n/ac/ax for compatibility with a wide range of Wi-Fi networks
- V1200 wireless-enabled hosts are tested for EN 50155 and an operating range of -40 to 70°C with cellular and Wi-Fi enabled
- Designed for railway TCMS data acquisition and train-to-ground applications

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 6 (802.11ax) module for the V1200 Series
- WLAN standards: 802.11a/b/g/n/ac/ax
- Frequency bands: 2.4 GHz and 5 GHz
- Host slot: M.2 E-key
- Package contents: Wi-Fi 6 module, 2 x coaxial cables (I-PEX 4 MHF male to QMA female), 1 x thermal pad, 1 x heat sink
- Host antenna connectors: QMA x 2 (V1222-CT-T, V1222-W-CT-T)
- Operating temperature (host with cellular and Wi-Fi): -40 to 70°C
- Storage temperature (package included): -40 to 85°C
- Ambient relative humidity: 5 to 95% (non-condensing)
- Radio approvals: FCC, RCM, CE (RED), UKCA

FAQs

Q: Which Moxa computers is the V1200-WLAN22-AX designed for?
A: It is an expansion module for the Moxa V1200 Series Arm-based rail computers and installs in the host's M.2 E-key slot.

Q: What is included in the kit?
A: The kit includes the Wi-Fi 6 module, two coaxial cables (I-PEX 4 MHF male to QMA female), one thermal pad and one heat sink.

Q: Which Wi-Fi standards does the module support?
A: It supports 802.11a/b/g/n/ac/ax, covering the 2.4 GHz and 5 GHz bands.

Q: What antenna connectors does the host use?
A: The V1222-CT-T and V1222-W-CT-T hosts provide two QMA antenna connectors, which the supplied I-PEX 4 MHF to QMA cables connect to.

Q: Can it operate in extended temperature environments?
A: V1200 hosts with cellular and Wi-Fi enabled are specified for operation from -40 to 70°C and are tested to EN 50155 for railway use.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
