Moxa UC-4400A-WLAN22-AX | UC-4400A Wi-Fi 6E M.2 Module Kit, 802.11ax, UC-443xA/445xA

Authorised Moxa Partner

SKU:UC-4400A-WLAN22-AX

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The UC-4400A-WLAN22-AX is a Wi-Fi 6E M.2 module kit for Moxa UC-4400A Series Arm-based industrial computers. It is built around an EMWICOM WMX7205-1 Wi-Fi 6E M.2 card and adds 802.11ax wireless networking across the 2.4 GHz, 5 GHz and 6 GHz bands to UC-443xA and UC-445xA models.

The kit installs in the M.2 E-key Wi-Fi slot and includes 2 heat sinks, 2 thermal pads and 2 x M2.5 x 5 mm screws for installation. It is compatible with the UC-4430A, UC-4434A, UC-4450A and UC-4454A, and the 6 GHz band is only available in countries that support Wi-Fi 6E.

Features

- Adds Wi-Fi 6E (802.11ax) wireless to UC-4400A Series computers
- Installs in the M.2 E-key socket
- Includes heat sinks and thermal pads for installation
- Tri-band 2.4 GHz, 5 GHz and 6 GHz operation
- 6 GHz band available only in countries supporting Wi-Fi 6E

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 6E 802.11ax M.2 card (EMWICOM WMX7205-1)
- Frequency bands: 2.4 GHz / 5 GHz / 6 GHz
- WLAN standards on UC-4400A with accessory: 802.11a/b/g/n/ac/ax
- Host slot: M.2 E-key slot (Wi-Fi) on UC-4400A
- Host Wi-Fi antenna connectors: RP-SMA x 2
- Included: 2 thermal pads, 2 heat sinks, 2 x M2.5 x 5 mm screws
- Compatible models: UC-4430A, UC-4434A, UC-4450A, UC-4454A
- Operating temperature of UC-4400A with Wi-Fi: -30 to 70 C (-22 to 158 F)
- 5925-6425 MHz range restricted to indoor use

FAQs

Q: Which Moxa computers is this Wi-Fi 6E kit compatible with?
A: It is designed for the UC-443xA and UC-445xA models, specifically the UC-4430A, UC-4434A, UC-4450A and UC-4454A.

Q: What is included in the kit?
A: The kit includes an EMWICOM WMX7205-1 Wi-Fi 6E M.2 card, 2 thermal pads, 2 heat sinks and 2 x M2.5 x 5 mm screws.

Q: Which slot does the module install in?
A: It installs in the M.2 E-key (Wi-Fi) slot on the UC-4400A, which connects to the host's two RP-SMA Wi-Fi antenna connectors.

Q: Which wireless standards and bands are supported?
A: A UC-4400A fitted with this accessory supports 802.11a/b/g/n/ac/ax across the 2.4 GHz, 5 GHz and 6 GHz bands.

Q: Is the 6 GHz band available in every country?
A: No. The 6 GHz band is only available in countries that support Wi-Fi 6E, and the 5925-6425 MHz range is restricted to indoor use.

Q: What operating temperature range applies with Wi-Fi fitted?
A: The UC-4400A with Wi-Fi fitted is rated for -30 to 70 C (-22 to 158 F).

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
