Moxa ANT-LTEUS-OSM-02 | LTEUS Omni Cellular Antenna, 698–960/1710–2700 MHz, SMA Male, 1.5 dBi, ANT

Moxa ANT-LTEUS-OSM-02 | LTEUS Omni Cellular Antenna, 698–960/1710–2700 MHz, SMA Male, 1.5 dBi, ANT

ANT-LTEUS-OSM-02

Stock Status: Enquire

$0.00 AUD
$0.00 AUD
$0.00 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

Compact 1/4‑wave omnidirectional antenna covering 698–960 and 1710–2700 MHz for broad LTE/3G/2G compatibility.. The SMA (male) connector and 1.5 dBi gain make it a straightforward, low‑loss choice for cellular routers, IoT gateways, and telemetry devices. Backed by the manufacturer’s warranty and designed for quick connector‑mount installation where a ground plane is available for optimal performance.. Available now at iptrading.com.au — competitive prices and local support.

Features

- Wideband coverage for LTE/3G/2G across 698–960 and 1710–2700 MHz
- Omnidirectional pattern simplifies placement and setup
- Compact 1/4‑wave design for discreet installations
- Direct SMA (male) connection minimises signal loss
- Works with Moxa and other devices using SMA (female) ports

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Frequency range: 698–960 MHz and 1710–2700 MHz
- Antenna type: 1/4‑wave omnidirectional
- Gain: 1.5 dBi
- Connector: SMA (male)

FAQs

Q: What devices is this antenna compatible with?
A: Any cellular router, gateway, modem, or IoT device with an SMA (female) antenna port operating in the 698–960 MHz and 1710–2700 MHz bands.

Q: Does this antenna support 5G?
A: It covers LTE/3G/2G bands (698–960/1710–2700 MHz). It does not cover common 5G mid‑band frequencies such as 3.5 GHz.

Q: Is the antenna omnidirectional?
A: Yes. It provides an omnidirectional pattern for general cellular coverage without alignment to a base station.

Q: How should I mount or orient the antenna?
A: Use the SMA connector to mount directly to your device, and keep the radiator vertical for best results. A ground plane (e.g., device chassis) is recommended for optimal performance.

Q: Do I need extra cables or adapters?
A: No extra cable is required if your device has an SMA (female) port. If not, use an appropriate RF adapter to match connector types.

Q: Can I purchase this antenna in Australia from IP Trading?
A: Yes. IP Trading supplies this model online with local support and invoicing in AUD at iptrading.com.au.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
