Logitech

Logitech 952-000019 | Cat5e Kit for Logitech Tap, 40m Single-Cable Extension

Logitech 952-000019 | Cat5e Kit for Logitech Tap, 40m Single-Cable Extension

Authorised Logitech Partner

SKU:952-000019

$556.93 inc. GST
$506.30 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

In stock: 20

Description

The Logitech Cat5e Kit for Logitech Tap is a single-cable video conferencing accessory kit that connects a Tap touch controller to the meeting room computer over category cabling. It carries both data and power on one run, so no power outlet is needed at the table, and it supports Tap placement up to 40 metres from the computer.

The kit includes a Tap Receiver, a Dongle Transceiver, a 100-240V power supply with international adaptors, and two Cat5e cables (2.97 m and 7.0 m). It works with the Logitech Tap Table, Riser and Wall Mounts in new and existing Logitech Room Solutions deployments. It provides a point-to-point USB extension over Cat5e and is not a network or IP connection.

Features

- Delivers data and power over one category cable, so no power outlet is needed at the table
- Flexible cabling: use the included cables or supply your own for runs up to 40 m
- Works with the Table, Riser and Wall Mounts for new and existing Logitech Room Solutions deployments
- Point-to-point USB extension over Cat5e, not a network or IP connection
- Cat5e allows precise cable lengths, reducing clutter under tables

Warranty

Logitech provides a limited hardware warranty for its business products, including headsets and video conferencing solutions. Warranty duration depends on the specific product:
• Headsets: Most Logitech business headsets, including the Logitech Zone series, come with a 2-year limited warranty from the date of purchase.
• Video Conferencing Solutions: Products such as Logitech Rally, MeetUp, and ConferenceCams are typically covered by a 2-year limited warranty.
Extended Warranty Options:
IP Trading offers extended warranty and support packages for Logitech business solutions, including flexible options to extend coverage by up to 3 years. Contact our team to learn more and protect your investment.
https://www.logitech.com/content/dam/logitech/en/video-collaboration/pdf/logitech-extended-warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Maximum distance: up to 40 m (131 ft) from the meeting room computer
- Compatible with Logitech Tap (Table, Riser and Wall Mounts)
- Cable type: Cat5e SF/UTP AWG26 or higher
- Power supply: 100-240V auto-switching with international adaptor set
- Included cables: 2.97 m (9.74 ft) and 7.0 m (22.96 ft) Cat5e
- Tap Receiver: 29 x 83 x 85 mm
- Dongle Transceiver: 22.5 x 31 x 83.7 mm with 500 mm cable
- Power supply: 91 x 60.2 x 36.3 mm (without plug)

FAQs

Q: How far can the Logitech Tap be from the meeting room computer with this kit?
A: Up to 40 metres (131 ft), using the included cables or your own Cat5e SF/UTP AWG26 or higher cable.

Q: Which Logitech Tap mounts is this kit compatible with?
A: It is compatible with Logitech Tap using the Table, Riser and Wall Mounts.

Q: Does the Tap need a separate power outlet at the table?
A: No. The kit delivers data and power over a single category cable, so no power outlet is required at the Tap location.

Q: What is included in the kit?
A: A Tap Receiver, a Dongle Transceiver, a 100-240V power supply with international adaptors, a 2.97 m Cat5e cable and a 7.0 m Cat5e cable.

Q: Can I connect the Tap through my network switch with this kit?
A: No. The kit provides a point-to-point USB extension over Cat5e cabling and is not a network or IP connection.

Q: Can I use my own cabling for longer runs?
A: Yes. You can supply your own Cat5e SF/UTP AWG26 or higher cable for runs up to 40 m.
