HPE S6X69A | CW 2050 28-Port Managed Switch, 4x Smart Rate 2.5G, 4x SFP, Fanless, 20x GbE

Name: HPE S6X69A | CW 2050 28-Port Managed Switch, 4x Smart Rate 2.5G, 4x SFP, Fanless, 20x GbE
Brand: HPE
SKU: S6X69A
Price: 726.51 AUD
Availability: BackOrder

Authorised HPE Partner

SKU:S6X69A

Stock Status: Enquire

$726.51 inc. GST

$660.46 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The HPE Networking CW 2050 is a fully managed, fanless Layer 2/3 access switch purpose-built for SMB and branch office environments where silent operation matters. Delivering 80 Gbps switching capacity across 20 Gigabit Ethernet ports, 4 Smart Rate 1/2.5GbE ports, and 4 SFP 1G/2.5G uplinks, it provides non-blocking, multi-gig performance in a compact, quiet form factor. IRF stacking supports up to two switches for simplified management and resilience.

Running HPE's FlexNetwork Comware OS, the CW 2050 supports Layer 3 static routing, IPv6, granular ACLs, 802.1X authentication, SSHv2/SSL/SNMPv3 encrypted access, and Secure Boot. Industry-leading 6 kV surge protection adds durability in demanding deployments. Managed via CLI, SNMP, REST API, or HPE IMC, it suits IT teams seeking enterprise-grade capability without complexity.

Features

- Fanless design eliminates fan noise — ideal for open-plan offices, classrooms, and noise-sensitive environments
- Two-switch Intelligent Resilient Fabric (IRF) stacking for high availability and unified management
- Smart Rate 1G/2.5GbE ports deliver multi-gig uplink bandwidth to APs and workstations over existing Cat5e/6 cabling
- Layer 3 static routing and full IPv6 support for flexible, future-ready network design
- Web GUI and embedded CW Dashboard for zero-touch-style simplified deployment
- Full management stack: CLI, SNMP, REST API, and HPE Intelligent Management Center (IMC)
- Granular ACLs (IPv4/IPv6, VLAN, and port-based) for precise traffic control
- Multi-factor authentication: 802.1X, MAC-based, Web auth, RADIUS, and TACACS+
- Encrypted management access via SSHv2, SSL, SNMPv3, and TLS
- Secure Boot prevents unauthorised firmware execution at startup
- Threat mitigation: DoS protection, ARP/DHCP snooping, ICMP throttling, and port security
- Private VLANs for granular user-to-user traffic isolation
- Industry-leading 6 kV surge protection for demanding or electrically noisy environments
- Ingress/egress port mirroring and Virtual Cable Testing (VCT) for proactive fault diagnosis

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 20 x 10/100/1000BASE-T Gigabit Ethernet ports
- 4 x Smart Rate 1G/2.5G BASE-T ports
- 4 x SFP 1G/2.5G uplink ports
- Total ports: 28
- Switching capacity: 80 Gbps
- Forwarding throughput: 59.52 Mpps
- Network OS: HPE FlexNetwork Comware
- Routing: Layer 3 Dynamic (static routing, IPv6)
- IRF stacking: up to 2 switches
- Fanless design — no moving parts
- Power consumption: Idle 8W / Typical 16W / Max 19W
- Surge protection: 6 kV (service port)
- Dimensions: 44 x 440 x 150 mm (1U)
- Weight: ~2.0 kg
- Non-PoE

FAQs

Q: Can I purchase the HPE S6X69A CW 2050 switch in Australia?
A: Yes. The HPE Networking CW 2050 (S6X69A) is available through iptrading.com.au, an Australian B2B IT hardware reseller offering expert pre-sales support and fast fulfilment.

Q: Does this switch support Power over Ethernet (PoE)?
A: No. The S6X69A is a Non-PoE model. If PoE is required for powering access points or IP phones, please check the HPE CW 2050 PoE variants within the same switch series.

Q: What is the Smart Rate port and why does it matter?
A: The 4 Smart Rate ports support 1G and 2.5G speeds over standard Cat5e/Cat6 cabling. This enables multi-gigabit connectivity to Wi-Fi 6/6E access points or high-performance workstations without rewiring — a cost-effective upgrade path.

Q: Is the CW 2050 suitable for noisy or open-plan environments?
A: Yes. The fanless design means zero fan noise, making it ideal for deployment in classrooms, open-plan offices, retail environments, or any location where acoustics are a concern.

Q: Can multiple CW 2050 switches be stacked together?
A: The CW 2050 supports IRF (Intelligent Resilient Fabric) stacking of up to 2 switches, allowing them to be managed as a single logical device for simplified administration and improved resilience.

Q: What management interfaces does the CW 2050 support?
A: The switch supports CLI, SNMP, REST API, Web GUI, and integration with HPE Intelligent Management Center (IMC). Secure access is enforced via SSHv2, SSL, SNMPv3, and TLS.
