HPE S3U30C | NVIDIA H200 NVL 141GB PCIe Gen5 GPU Accelerator, 600W

Authorised HPE Partner

SKU:S3U30C

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The NVIDIA H200 NVL 141GB PCIe Gen5 GPU accelerator is a dual-slot, air-cooled data-centre card built on the NVIDIA Hopper architecture, rated up to 600W. With 141GB of HBM3e memory and 4.8 TB/s of memory bandwidth, it is designed for generative AI, large language model inference and high-performance computing workloads in compatible HPE servers.

The card supports a 2- or 4-way NVLink bridge at 900 GB/s per GPU for multi-GPU scaling, plus Multi-Instance GPU partitioning of up to seven instances at 16.5GB each. Confidential computing is supported and an NVIDIA AI Enterprise add-on is included, making it suited to shared and secure AI infrastructure deployments.

Features

- First GPU with HBM3e memory, 141GB at 4.8 TB/s
- Nearly double the memory capacity of the H100 with 1.4X the memory bandwidth
- Up to 1.9X faster Llama2 70B inference and 1.6X faster GPT-3 175B inference (NVIDIA figures)
- Up to 110X faster HPC workloads (NVIDIA figure)
- Confidential computing support for secure AI workloads
- Multi-Instance GPU partitioning for up to 7 isolated instances
- NVLink bridge support for multi-GPU scaling
- NVIDIA AI Enterprise add-on included

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- NVIDIA H200 NVL (Hopper) Tensor Core GPU
- 141GB HBM3e GPU memory
- 4.8 TB/s memory bandwidth
- PCIe Gen5 x16 interface (128 GB/s)
- Up to 600W maximum TDP (configurable)
- Dual-slot, air-cooled PCIe form factor
- 2- or 4-way NVLink bridge, 900 GB/s per GPU
- Up to 7 Multi-Instance GPUs at 16.5GB each
- FP64: 30 TFLOPS, FP64 Tensor Core: 60 TFLOPS, FP32: 60 TFLOPS
- FP8 Tensor Core (with sparsity): 3,341 TFLOPS
- 7 NVDEC and 7 JPEG decoders
- Confidential computing supported
- NVIDIA AI Enterprise add-on included

FAQs

Q: What memory does the H200 NVL have?
A: It has 141GB of HBM3e memory with 4.8 TB/s of memory bandwidth, nearly double the capacity of the H100 and 1.4X the bandwidth.

Q: What host interface and form factor does this card use?
A: It uses a PCIe Gen5 x16 interface (128 GB/s) in a dual-slot, air-cooled PCIe form factor.

Q: Can multiple H200 NVL cards be linked together?
A: Yes. The card supports a 2- or 4-way NVIDIA NVLink bridge delivering 900 GB/s per GPU for multi-GPU scaling.

Q: Does it support GPU partitioning?
A: Yes. Multi-Instance GPU technology allows up to 7 instances, each with 16.5GB of memory.

Q: What is the maximum power draw?
A: The maximum thermal design power is up to 600W and is configurable, so the host server needs sufficient power delivery and airflow for the card.

Q: Is NVIDIA AI Enterprise included?
A: An NVIDIA AI Enterprise add-on is included with this accelerator.
