HPE S3T54C | RTX 4000 Ada Graphics Card, 20GB GDDR6, PCIe Gen4

Name: HPE S3T54C | RTX 4000 Ada Graphics Card, 20GB GDDR6, PCIe Gen4
Brand: HPE
SKU: S3T54C
Price: 7644.72 AUD
Availability: BackOrder

Authorised HPE Partner

SKU:S3T54C

Stock Status: Enquire

$7,644.72 inc. GST

$6,949.75 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The HPE S3T54C is an NVIDIA RTX 4000 Ada graphics accelerator with 20GB GDDR6 ECC memory, a PCIe Gen4 x16 interface and a single-slot design. Built on the NVIDIA Ada Lovelace architecture with 6,144 CUDA cores, 192 4th-gen Tensor Cores and 48 3rd-gen RT Cores, it is suited to 3D modelling, CAD and CAE, rendering, video streaming and AI inference in HPE Gen11 servers.

Qualified by HPE for the DL380 Gen11, ML350 Gen11, ML110 Gen11 and ML30 Gen11, the card draws 130 W total board power and uses active cooling. Four DisplayPort 1.4a outputs support high-resolution multi-display setups, while AV1 encode and decode and NVIDIA GPUDirect for Video and RDMA support help video and data pipeline workloads.

Features

- Up to 1.5x FP32 throughput over the previous generation for CAD, CAE and simulation workflows
- 3rd-gen RT Cores deliver up to 2x ray-tracing throughput
- 4th-gen Tensor Cores deliver up to 3x AI performance and support FP8
- AV1 encode and decode support for efficient video streaming and transcoding
- NVIDIA GPUDirect for Video and RDMA support
- 20GB ECC GDDR6 memory for large datasets and complex scenes
- Single-slot design for dense server configurations
- Qualified by HPE for Gen11 ProLiant and ML servers

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- NVIDIA Ada Lovelace architecture
- 20 GB GDDR6 memory, 160-bit interface, ECC
- 360 GB/s memory bandwidth
- 6,144 CUDA cores
- 192 4th-gen Tensor Cores
- 48 3rd-gen RT Cores
- 26.7 TFLOPS single-precision performance
- 61.8 TFLOPS RT Core performance
- 327.6 TFLOPS Tensor performance
- PCIe 4.0 x16 system interface
- 130 W total board power
- Active thermal solution
- Single-slot form factor, 4.4 in H x 9.5 in L
- 4x DisplayPort 1.4a
- Supports 4x 4096x2160 @120Hz, 4x 5120x2880 @60Hz or 2x 7680x4320 @60Hz displays
- 2x encode and 2x decode engines, with AV1 encode and decode
- DirectX 12, OpenGL 4.6 and Vulkan 1.3 graphics APIs
- CUDA 12.2, OpenCL 3.0 and DirectCompute compute APIs
- Weight: 1.02 kg

FAQs

Q: Which HPE servers is the S3T54C compatible with?
A: The S3T54C is listed for the HPE ProLiant DL380 Gen11, ML350 Gen11, ML110 Gen11 and ML30 Gen11.

Q: How much power does the NVIDIA RTX 4000 Ada draw?
A: Total board power is 130 W, so confirm your server has the required GPU power provisioning before installation.

Q: Does this card occupy one or two slots?
A: It is a single-slot card measuring 4.4 in high by 9.5 in long, with an active cooling solution.

Q: What PCIe interface does the S3T54C use?
A: It uses a PCIe 4.0 x16 system interface.

Q: What workloads is the RTX 4000 Ada suited to?
A: It targets 3D modelling, CAD and CAE, rendering, video streaming and AI inference, using its CUDA, Tensor and RT Cores.

Q: How many displays can it drive?
A: It has four DisplayPort 1.4a outputs and supports up to four 4096x2160 displays at 120Hz, four 5120x2880 displays at 60Hz or two 7680x4320 displays at 60Hz.
