Aruba R1T38A | DL360 Gen10 500W Flex Slot Spare Power Supply, 240V, AU Plug

Name: Aruba R1T38A | DL360 Gen10 500W Flex Slot Spare Power Supply, 240V, AU Plug
Brand: Aruba
SKU: R1T38A
Price: 1388.29 AUD
Availability: BackOrder

Authorised Aruba Partner

SKU:R1T38A

Stock Status: Enquire

$1,388.29 inc. GST

$1,262.08 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

This 500W Flex Slot hot-plug power supply is a spare for the HPE ProLiant DL360 Gen10 server, supplied for 240V use with an AU plug. It is 80 PLUS Platinum certified with efficiency of up to 94%, helping to reduce wasted power in the rack, and it supports redundant power supply configurations so a failed module can be replaced without taking the server offline.

The Flex Slot form factor is 25% smaller than the previous generation Common Slot design, freeing space inside the chassis for server options. It accepts 100-240V AC input at 50-60 Hz and uses tool-less hot-plug access for fast servicing. The same module is supported across HPE ProLiant Gen10 servers, ProLiant 300 Gen9, and Apollo 2000 and Apollo 4000 series systems.

Features

- Tool-less hot-plug access for easier serviceability
- Flex Slot form factor is 25% smaller than Common Slot power supplies, freeing space for server options
- Supports redundant power supply configurations
- 80 PLUS Platinum efficiency to cut server power waste
- Supported across HPE ProLiant Gen10, ProLiant 300 Gen9, Apollo 2000 and Apollo 4000 series

Warranty

Aruba Networking offers a Limited Lifetime Warranty on many of its hardware products, including select switches and access points. This warranty covers defects in materials and workmanship for the duration of the product's life, with support available for up to five years after the product's end-of-sale date.
Other Aruba products come with warranties ranging from 1 to 5 years, depending on the specific model. Warranty terms can vary based on the product category and model number.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Aruba Networking products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.hpe.com/psnow/doc/a00143138enw?jumpid=in_pdfviewer-psnow

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Maximum rated output power: 500W
- Form factor: Flex Slot hot-plug, redundant plug-in module
- 80 PLUS Platinum certified, peak efficiency 94%
- Input voltage: 100-240V AC, 50-60 Hz
- Efficiency at 240V nominal input: 93.1%
- Nominal input current at 240V: 2.3A
- Maximum rated input power at 240V: 537W
- Power factor: 0.99
- Maximum inrush current: 30A peak for 10 ms
- Maximum heat output at 240V: 1832 BTU/hr
- Compatible with HPE ProLiant DL360 Gen10 server
- Low halogen design

FAQs

Q: Which server is this power supply designed for?
A: It is a spare power supply for the HPE ProLiant DL360 Gen10 server. The Flex Slot module is also supported across other HPE ProLiant Gen10 servers, ProLiant 300 Gen9, and Apollo 2000 and Apollo 4000 series systems.

Q: Is this power supply hot-plug?
A: Yes. It is a hot-plug Flex Slot module with tool-less access, so it can be replaced while the server is running when used in a redundant power supply configuration.

Q: What input voltage does it support?
A: It accepts 100-240V AC input at 50-60 Hz. This SKU is supplied for 240V use with an AU plug.

Q: What efficiency rating does it have?
A: It is 80 PLUS Platinum certified, with peak efficiency of up to 94% and 93.1% at 240V nominal input.

Q: Can I use it for redundant power?
A: Yes. It supports redundant power supply configurations, so a second module can be installed in the server to keep it running if one supply fails.

Q: How does the Flex Slot form factor differ from earlier designs?
A: Flex Slot modules are 25% smaller than the previous generation Common Slot power supplies, which frees up chassis space for other server options.
