HPE P80409-B21 | ProLiant DL580 Gen12 Cable Kit, 16SFF, 2P/4P, x2 OCP

HPE P80409-B21 | ProLiant DL580 Gen12 Cable Kit, 16SFF, 2P/4P, x2 OCP

Authorised HPE Partner

P80409-B21

Stock Status: Enquire

$1,182.16 inc. GST
$1,074.69 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The HPE ProLiant DL580 Gen12 internal cable kit for 16SFF, 2P/4P configurations connects a 16-drive small form factor layout (drive boxes 3 + 4) to OCP-form-factor OROC tri-mode storage controllers installed in both rear OCP slots, OCP A and OCP B. It is designed for the ProLiant Compute DL580 Gen12 with Intel Xeon 6 processors and requires two HPE MR416i-o or MR216i-o controllers.

The kit is configured automatically based on the drive cage and riser selections, so it enables 16 SFF drives to be driven from two OCP-slot OROC controllers without sourcing individual cable runs. It is intended for 2P/4P builds that use the OCP slots for storage control rather than a PCIe-slot controller.

Features

- Connects a 16 SFF drive layout to two OCP-slot OROC tri-mode controllers
- Configured automatically based on the drive cage and riser selections
- Designed for the DL580 Gen12 with Intel Xeon 6 processors
- Supports 2P/4P server configurations

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: P80409-B21
- Compatible server: HPE ProLiant Compute DL580 Gen12 (2P/4P configurations)
- Drive configuration: 16SFF (drive boxes 3 + 4)
- Protocol: OROC tri-mode
- Slots used: OCP A + OCP B
- Required controller: HPE MR416i-o or MR216i-o, quantity 2
- Shipping weight: approx. 0.67 kg (1.48 lb)
- UNSPSC: 26121600

FAQs

Q: Which server is the P80409-B21 cable kit designed for?
A: It is an internal cable kit for the HPE ProLiant Compute DL580 Gen12 in 2P/4P configurations.

Q: Which storage controllers are required with this kit?
A: Two HPE MR416i-o or MR216i-o OROC tri-mode controllers are required, one in each rear OCP slot.

Q: Which OCP slots does this kit use?
A: It uses both OCP A and OCP B, so both rear OCP slots are occupied by the storage controllers.

Q: How many drives does this kit support?
A: It supports a 16SFF drive configuration covering drive boxes 3 and 4.

Q: Is this kit for single-processor DL580 Gen12 builds?
A: No. It is specified for 2P/4P DL580 Gen12 configurations.

Q: Do I need to choose the cabling separately for my drive cage and risers?
A: The kit is configured automatically based on the drive cage and riser selections made for the server build.
