HPE P80389-B21 | DL580 Gen12 Tri-Mode Cable Kit, 24SFF x1, PCIe 7+8

HPE P80389-B21 | DL580 Gen12 Tri-Mode Cable Kit, 24SFF x1, PCIe 7+8

Authorised HPE Partner

P80389-B21

Stock Status: Enquire

$760.15 inc. GST
$691.05 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The HPE P80389-B21 is an internal Tri-Mode (U.3, SAS, SATA and NVMe) storage cable kit for the HPE ProLiant Compute DL580 Gen12 in 2P/4P configurations. It connects a 24SFF x1 drive-cage layout to Tri-Mode storage controllers installed in PCIe slots 7 and 8, making it the right choice when a DL580 Gen12 build calls for a 24 small form factor bay arrangement.

The kit spans drive boxes 3, 4 and 6 in the DL580 Gen12 chassis and uses two PCIe slots for the controllers. Per the HPE QuickSpecs, the required controllers are two MR416i-p or MR216i-p units. Cable kits are configured automatically based on the drive cage and riser selections, so this part suits builds that match the 24SFF x1, PCIe 7+8 layout.

Features

- Supports 24 SFF drive bays via Tri-Mode connectivity (NVMe, SAS and SATA)
- Spans three drive boxes (3, 4 and 6) in the DL580 Gen12 chassis
- Uses two PCIe slots (7 and 8) for the storage controllers
- Configured automatically by HPE based on drive cage and riser selection

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: P80389-B21
- Product type: Internal storage cable kit
- Drive configuration: 24SFF x1
- Protocol: Tri-Mode (PCIe TM), supporting NVMe, SAS and SATA
- Drive boxes used: 3 + 4 + 6
- Slots used: PCIe 7 + 8
- Required controllers: 2 x MR416i-p or MR216i-p
- Server compatibility: HPE ProLiant Compute DL580 Gen12, 2P/4P configurations

FAQs

Q: Which server is the P80389-B21 cable kit designed for?
A: It is designed for the HPE ProLiant Compute DL580 Gen12 in 2P/4P (two or four processor) configurations.

Q: Which storage controllers does this cable kit require?
A: Per the HPE QuickSpecs, it requires two MR416i-p or MR216i-p controllers installed in PCIe slots 7 and 8.

Q: What drive configuration does this kit support?
A: It supports a 24SFF x1 configuration, connecting drive boxes 3, 4 and 6 using Tri-Mode connectivity.

Q: Which drive protocols are supported?
A: The kit uses the Tri-Mode (PCIe TM) protocol, which supports NVMe, SAS and SATA drives.

Q: Do I need to select this cable kit manually?
A: HPE configures cable kits automatically based on the drive cage and riser selections, so this kit applies to builds that use the 24SFF x1, PCIe 7+8 layout.
