HPE P77556-B21 | ProLiant DL3X0 Gen12 OCP Slot B Direct Attach MXIO Cable Kit

Name: HPE P77556-B21 | ProLiant DL3X0 Gen12 OCP Slot B Direct Attach MXIO Cable Kit
Brand: HPE
SKU: P77556-B21
Price: 96.05 AUD
Availability: BackOrder

Authorised HPE Partner

SKU:P77556-B21

Stock Status: Enquire

$96.05 inc. GST

$87.32 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The HPE P77556-B21 is a direct attach OCP Slot B MXIO cable kit for HPE ProLiant DL3X0 Gen12 servers, including the DL320 and DL340 Gen12. It connects the optional rear OCP 3.0 Slot B directly to the motherboard riser connector, enabling an OCP 3.0 network adapter to be installed in that slot.

The direct attach design connects straight to the MLB riser connector, so no OCP RAID controller or MCIO cabling is required for this connection. The kit is listed as a platform-compatible option in the DL320 Gen12 QuickSpecs and supports the rear OCP B slot, which runs PCIe 5.0 x16.

Features

- Enables the optional rear OCP 3.0 Slot B on DL3X0 Gen12 servers
- Direct attach to the MLB riser connector
- No OCP RAID controller or MCIO cabling needed for this connection
- Listed in the DL320 Gen12 QuickSpecs as a common cable kit

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: P77556-B21
- Type: Direct Attach cable kit for rear OCP 3.0 Slot B
- Connection: connects directly to the MLB riser connector
- Compatible with HPE ProLiant Compute DL320 Gen12 and DL340 Gen12 (DL3X0 Gen12)
- Supported OCP slot: rear OCP B (OCP 3.0, optional), PCIe 5.0 x16

FAQs

Q: Which servers is the P77556-B21 compatible with?
A: It is designed for HPE ProLiant Compute DL3X0 Gen12 servers, including the DL320 Gen12 and DL340 Gen12.

Q: What does this cable kit connect?
A: It connects the rear OCP 3.0 Slot B directly to the motherboard (MLB) riser connector.

Q: Do I need additional MCIO cabling or an OCP RAID controller?
A: No. This direct attach kit connects directly to the MLB riser connector, so no OCP RAID controller or MCIO cabling is needed for this connection.

Q: Is the OCP Slot B included with the server?
A: The rear OCP 3.0 Slot B is an optional configuration on DL3X0 Gen12 servers, and this cable kit is the option used to enable it.

Q: What interface does the supported OCP slot use?
A: The rear OCP B slot supported by this kit is OCP 3.0 and runs PCIe 5.0 x16.
