• Rows of sleek dark gray server racks in a white-tiled corridor showcasing hpe proliant dl345 gen11 24sff nvme kit
1 1

HPE

HPE P57125-B21 | ProLiant DL345 Gen11 24SFF x4 NVMe Cable Kit, Box 1-3

HPE P57125-B21 | ProLiant DL345 Gen11 24SFF x4 NVMe Cable Kit, Box 1-3

Authorised HPE Partner

P57125-B21

Stock Status: Enquire

$4,822.21 inc. GST
$4,383.83 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

This HPE ProLiant DL345 Gen11 24SFF x4 NVMe direct attach cable kit connects 24 SFF U.3 NVMe drives across drive boxes 1-3, delivering x4 PCIe bandwidth to every drive. It is designed for the ProLiant DL345 Gen11 and enables a full 24SFF front NVMe configuration with direct attach cabling in Box 1-3.

The kit includes the power cables for box 1, box 2 and box 3 and is used with three 8SFF x4 U.3 backplanes. It requires two OCP retimers and can only be selected with the 8SFF CTO server configuration. Where x2 bandwidth is sufficient, an alternative 24SFF x2 Tri-Mode Box 1-3 cable kit is also available.

Features

- Enables x4 NVMe direct attach for a 24SFF front configuration
- Supports 24 SFF U.3 NVMe drives across Box 1-3
- Used with 3 x 8SFF x4 U.3 backplanes
- Includes power cables for box 1, box 2 and box 3
- Can only be selected with the 8SFF CTO server configuration

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: P57125-B21
- Compatible server: HPE ProLiant DL345 Gen11
- Function: 24SFF NVMe x4 Direct Attach cabling, Box 1-3
- Drive support: 24 SFF U.3 NVMe
- Bandwidth: x4 PCIe per drive
- Requirement: two (2) OCP retimers (e.g. P65876-B21)
- Related backplane: 8SFF x4 U.3 backplane (P55083-B21)
- Contents: power cables for box 1, box 2 and box 3 plus NVMe data cables

FAQs

Q: Which server is the P57125-B21 cable kit compatible with?
A: It is designed for the HPE ProLiant DL345 Gen11 server.

Q: How many drives does this cable kit support?
A: It supports 24 SFF U.3 NVMe drives in Box 1-3 direct attach, with x4 PCIe bandwidth per drive.

Q: Does this kit require any additional components?
A: Yes. It requires two OCP retimers (for example P65876-B21) and is used with three 8SFF x4 U.3 backplanes such as P55083-B21.

Q: Can I select this kit with any DL345 Gen11 configuration?
A: No. It can only be selected with the 8SFF CTO server configuration.

Q: Is there an option with lower bandwidth per drive?
A: Yes. The 24SFF x2 Tri-Mode Box1-3 Cable Kit (P57129-B21) is the alternative x2 option.

Q: What is included in the kit?
A: The kit contains the power cables for box 1, box 2 and box 3, along with the NVMe data cables for direct attach.
