Aruba JW055A | AP-270-MNT-H2 Flush Wall/Ceiling AP Mount Kit
Aruba JW055A | AP-270-MNT-H2 Flush Wall/Ceiling AP Mount Kit
Authorised Aruba Partner
SKU:JW055A
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The AP-270-MNT-H2 is a flush, non-articulating wall and ceiling mount kit for Aruba 270 Series outdoor access points. It holds the AP close to the mounting surface and suits models such as the AP-277 that face out towards the coverage area. The bracket also acts as a drilling template for the four mounting points, which simplifies installation.
The kit includes the mounting bracket, two M6 x 20 screws and an installation guide. The AP slides into the holder and is secured with the supplied screws. It is compatible with the AP-274, AP-275 and AP-277, as well as later outdoor models including the AP-318, AP-365, AP-367, AP-374, AP-375 and AP-377. Anchor bolts, washers and nuts are required for wall mounting and are not included.
Features
Features
- Flush mounting keeps the AP close to the wall or ceiling surface
- Non-articulating bracket suited to APs, such as the AP-277, that face out towards the coverage area
- Bracket doubles as a drilling template for the four mounting points
- Slide-in AP holder secured with two M6 x 20 screws
Warranty
Warranty
Aruba Networking offers a Limited Lifetime Warranty on many of its hardware products, including select switches and access points. This warranty covers defects in materials and workmanship for the duration of the product's life, with support available for up to five years after the product's end-of-sale date.
Other Aruba products come with warranties ranging from 1 to 5 years, depending on the specific model. Warranty terms can vary based on the product category and model number.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Aruba Networking products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.hpe.com/psnow/doc/a00143138enw?jumpid=in_pdfviewer-psnow
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: JW055A
- Model: AP-270-MNT-H2
- Mount type: Flush wall or ceiling, non-articulating
- Package contents: mounting bracket x 1, M6 x 20 screws x 2, installation guide
- Wall mounting points: 4 (hole diameter 8.3 mm)
- Not included: anchor bolts, washers and nuts (required for wall mounting)
- Tools required: #1 Phillips screwdriver, electric drill with bits
- Colour: White
- Compatible APs: AP-274, AP-275, AP-277, AP-318, AP-365, AP-367, AP-374, AP-375, AP-377
FAQs
Q: Which access points does the AP-270-MNT-H2 support?
A: It supports the AP-274, AP-275 and AP-277, as well as later outdoor models including the AP-318, AP-365, AP-367, AP-374, AP-375 and AP-377.
Q: Is this mount articulating?
A: No. The AP-270-MNT-H2 is a flush, non-articulating bracket, so the AP sits at a fixed angle against the wall or ceiling surface.
Q: What is included in the box?
A: One mounting bracket, two M6 x 20 screws and an installation guide.
Q: Are anchor bolts included for wall mounting?
A: No. Anchor bolts, washers and nuts are required for wall mounting and are not included in the kit.
Q: What tools do I need to install it?
A: You need a #1 Phillips screwdriver and an electric drill with suitable bits. The bracket can be used as a template to mark the four mounting holes.
Q: Can it be mounted on both walls and ceilings?
A: Yes. The kit is designed for flush mounting on either a wall or a ceiling.
