Fortinet FNC-CA-600F | FortiNAC F Series NAC Appliance, 30, 000 Endpoints, 1U

Fortinet FNC-CA-600F | FortiNAC F Series NAC Appliance, 30, 000 Endpoints, 1U

Authorised Fortinet Partner

FNC-CA-600F

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FortiNAC-CA-600F is a 1U rack-mount network access control appliance from the FortiNAC F Series, built as a high performance Control and Application server for medium environments. It manages up to 30,000 endpoints and delivers network visibility, Zero Trust access control and automated incident response across wired, wireless and VPN connections. Powered by an AMD EPYC 7413 24-core CPU with 32GB DDR4 memory, it handles up to 1,500 managed FortiGates.

The appliance discovers and profiles every device on the network, including BYOD, IoT, OT and IoMT, then applies role-based access and micro-segmentation policies. It integrates with FortiGate, FortiSIEM, FortiAnalyzer, FortiEDR, FortiSwitch, FortiAP and more than 90 third-party vendors, and supports active/passive High Availability and N+1 failover groups. PLUS or PRO FortiNAC licensing is required and sold separately.

Features

- Discovers and maintains an inventory of all network devices, including BYOD, IoT, OT and IoMT
- Continuous endpoint risk assessment using FortiGuard threat intelligence and behavioural patterns
- Device profiling with 27 native FortiNAC categories plus 133 FortiGuard categories, using 21 profiling methods
- Micro-segmentation and Zero Trust role-based network access control
- Automated threat response that quarantines non-compliant or compromised endpoints
- Integrates with FortiGate, FortiSIEM, FortiAnalyzer, FortiEDR, FortiSwitch, FortiAP and more than 90 third-party vendors
- High Availability (active/passive) and N+1 failover group support
- Out-of-band architecture, managed centrally via FortiNAC-M Manager for up to 100 CA servers

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Managed endpoints: up to 30,000
- Managed FortiGates: up to 1,500
- FortiGate with FortiSwitch (FortiLink): up to 800
- CPU: AMD EPYC 7413 24-core, 2.65GHz base frequency
- Memory: 32GB DDR4
- Storage: 2x 960GB SSDs, software RAID1
- Network interfaces: 1x GbE RJ45 and 4x 1GbE SFP or 10GbE SFP+
- Console access: RJ45 COM port for CLI
- Form factor: 1U rack mount
- Dimensions (H x W x L): 44 x 437 x 610 mm
- Weight: 18.6 kg
- Power supply: hot-plug 1+1 redundant PSU, 225W input
- Cooling: 5x system fans
- Heat dissipation: 767.73 BTU/h
- Operating temperature: 0 to 40°C
- Humidity: 5% to 90% non-condensing
- Certifications: NRTL, SCC, CE, FCC, ICES, RoHS

FAQs

Q: How many endpoints does the FortiNAC-CA-600F support?
A: It supports up to 30,000 managed endpoints and up to 1,500 managed FortiGates, making it suited to medium environments.

Q: Does the FortiNAC-CA-600F include FortiNAC licences?
A: No. It requires PLUS or PRO FortiNAC licensing, which is sold separately. FortiCare support provides firmware updates and the FortiGuard IoT service.

Q: What network interfaces does it have?
A: It provides 1x GbE RJ45 and 4x 1GbE SFP or 10GbE SFP+ interfaces, plus an RJ45 COM port for CLI console access.

Q: Does it support redundancy?
A: Yes. It has a hot-plug 1+1 redundant power supply, 2x 960GB SSDs in software RAID1, and supports active/passive High Availability and N+1 failover groups.

Q: Can multiple appliances be managed centrally?
A: Yes. FortiNAC-M Manager can centrally manage up to 100 CA servers in an out-of-band architecture.

Q: Which third-party products does it integrate with?
A: It integrates with FortiGate, FortiSIEM, FortiAnalyzer, FortiEDR, FortiSwitch and FortiAP, plus more than 90 third-party vendors.
