• Back view of Check Point CPAP-SG1575R-SNBT-AC 1575R rugged firewall with ports
1 1

Check Point

Check Point CPAP-SG1575R-SNBT-AC | Quantum Rugged 1575R Industrial Firewall, SandBlast, AC PSU

Check Point CPAP-SG1575R-SNBT-AC | Quantum Rugged 1575R Industrial Firewall, SandBlast, AC PSU

Authorised Check Point Partner

CPAP-SG1575R-SNBT-AC

Stock Status: Enquire

$4,905.83 inc. GST
$4,459.85 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Check Point Quantum Rugged 1575R is a fanless, solid-state rugged industrial firewall built for OT, SCADA and ICS networks. This wired SKU bundles the SandBlast (SNBT) security subscription, including Threat Emulation sandboxing, with an industrial-grade AC power supply, so it is ready to deploy in harsh environments. It delivers 1,970 Mbps of firewall throughput and 400 Mbps of threat prevention throughput with eight 1GbE LAN ports plus SFP-capable WAN and DMZ ports.

The aluminium fanless design operates from -40°C to 75°C and supports desktop, wall-mount and DIN-rail installation. It identifies and secures more than 70 standard and proprietary SCADA and ICS protocols, including Modbus, DNP3, BACnet, IEC 61850, Profinet and Step7, and offers redundant power inputs plus an onboard serial port for legacy industrial equipment.

Features

- Next Generation Firewall with site-to-site and remote access VPN
- SandBlast Threat Emulation sandboxing included with SNBT subscription
- Application Control and Web Filtering
- Intrusion Prevention, Anti-Virus, Anti-Bot and Anti-Spam
- Identifies and secures 70+ standard and proprietary SCADA/ICS protocols
- Device Recognition for visibility of connected industrial assets
- Redundant power inputs for continuous operation
- High Availability clustering of two units
- Fanless solid-state design for harsh industrial and maritime environments
- Flexible desktop, wall-mount and DIN-rail installation

Warranty

Check Point hardware appliances come with a 1-year limited hardware warranty.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Check Point products, ensuring your security infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.checkpoint.com/support-services/software-license-agreement-limited-hardware-warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 8 x 1GbE LAN ports
- 1 x 1GbE/SFP WAN port
- 1 x 1GbE/SFP DMZ port
- Serial port (DB9) RS232/RS422/RS485, software configurable
- USB Type-C console port, 1 x USB 3.0, SD card support
- Firewall throughput: 1,970 Mbps
- Threat Prevention throughput: 400 Mbps
- Next Generation Firewall throughput: 830 Mbps
- IPS throughput: 1,000 Mbps
- VPN AES-128 throughput: 1,100 Mbps
- Connections per second: 14,600
- Concurrent connections: 1,200,000
- Power inputs: 12VDC industrial AC adapter (120W) and 3-pin terminal block (12-60VDC nominal)
- Redundant power supported when both inputs are connected
- Maximum power consumption: 25.1 W
- Operating temperature: -40°C to 75°C
- Fanless aluminium design, IP30
- Dimensions (H x W x D): 90 x 150 x 150 mm
- Desktop, wall-mount and DIN-rail installation
- Certifications: IEEE 1613, IEC 61850-3, IEC 60945, EN/IEC 60529
- Operating system: Gaia Embedded (R81.10 / R82)

FAQs

Q: What is included with the CPAP-SG1575R-SNBT-AC?
A: This SKU is the wired Quantum Rugged 1575R security gateway bundled with the SandBlast (SNBT) security subscription, which includes Threat Emulation sandboxing, and an industrial-grade AC power supply.

Q: Which industrial protocols can the 1575R secure?
A: It identifies and secures more than 70 standard and proprietary SCADA and ICS protocols, including BACnet, DNP3, IEC 61850, Modbus, Profinet and Step7.

Q: What temperature range does it support?
A: The fanless aluminium chassis is rated for operation from -40°C to 75°C, making it suitable for harsh industrial environments.

Q: How can the 1575R be mounted?
A: It supports desktop, wall-mount and DIN-rail installation, with rear or bottom DIN-rail adapters available.

Q: Can it connect to legacy serial equipment?
A: Yes. It has a DB9 serial port that is software configurable for RS232, RS422 or RS485.

Q: Does it support power redundancy?
A: Yes. It has two power inputs, an external 12VDC industrial adapter and a 3-pin terminal block, and redundancy is supported when both are connected.

Q: Can two units be deployed for High Availability?
A: Yes. The 1575R can be deployed in a High Availability cluster of two units.
