Check Point

Check Point CPAC-4-10/25F-DA | Quantum Force 4-Port 10G/25G SFP28 Accelerated NIC

Check Point CPAC-4-10/25F-DA | Quantum Force 4-Port 10G/25G SFP28 Accelerated NIC

CPAC-4-10/25F-DA

Stock Status: Enquire

$9,107.42 AUD
$9,107.42 AUD
$9,107.42 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The CPAC-4-10/25F-DA is a hardware-accelerated 4-port 10G/25G expansion line card designed for Check Point Quantum Force 9000, 19000, and 29000 series security appliances. Leveraging Nvidia ASIC technology, it delivers line-rate firewall acceleration across all four SFP+ / SFP28 ports, supporting both 10GBase-F (SFP+) and 25GBase-F (SFP28) fibre interfaces. It is the accelerated variant of the CPAC-4-10/25F-D, visually identified by the 'Acceleration' label on its lower right corner, making it the preferred choice for high-throughput enterprise and data centre security deployments.

This modular interface card slots directly into compatible Quantum Force appliances and supports Check Point-approved SFP+ and SFP28 transceivers as well as 25GBASE-CR1 DAC cables up to 3 metres. Minimum software requirement is R81.20 Jumbo Hotfix Accumulator Take #101 or R82 Take #36. A future roadmap includes IPSec VPN and additional capability acceleration. Note: Maestro support is planned for a later release. Available now at iptrading.com.au — your local source for enterprise-grade networking solutions.

Features

- Hardware-accelerated firewall throughput at line-rate using Nvidia ASIC technology
- Dual-speed flexibility: supports both 10GbE (SFP+) and 25GbE (SFP28) fibre interfaces per port
- Modular line card design for easy slot installation in supported Quantum Force appliances
- Acceleration capability aligned with the CPAC-2-40/100F-D NIC platform
- Supports a range of Check Point-approved SFP+ and SFP28 transceivers for SR, LR, and ER applications
- DAC cable support for cost-effective short-reach 25G interconnects (up to 3m)
- Future roadmap includes IPSec VPN acceleration and additional security function offload
- Clearly labelled 'Acceleration' variant to distinguish from non-accelerated CPAC-4-10/25F-D

Warranty

Check Point hardware appliances come with a 1-year limited hardware warranty.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Check Point products, ensuring your security infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.checkpoint.com/support-services/software-license-agreement-limited-hardware-warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 4 x SFP+ / SFP28 ports (10GBase-F / 25GBase-F)
- Port speeds: 10GbE (SFP+) or 25GbE (SFP28) per port
- Hardware acceleration via Nvidia ASIC technology
- Compatible appliances: Quantum Force 9100, 9200, 9300, 9400, 9700, 9800, 19000, 29000 series
- Minimum software: R81.20 Jumbo Hotfix Accumulator Take #101 or R82 Take #36
- DAC cable support: 25GBASE-CR1 SFP28, up to 3m (SFF-8402, SFF-8436 compliant)
- Compatible transceivers: CPAC-TR-10SR-D, CPAC-TR-10LR-D, CPAC-TR-10ER-D, CPAC-TR-25SR-D, CPAC-TR-25LR-D
- Maestro support: planned for future release (not currently supported)
- Gaia OS port naming: eth<X>-01 through eth<X>-0<Y> based on slot number
- Form factor: modular expansion line card

FAQs

Q: Which Check Point appliances are compatible with the CPAC-4-10/25F-DA?
A: The CPAC-4-10/25F-DA is compatible with Check Point Quantum Force 9100, 9200, 9300, 9400, 9700, 9800, 19000, and 29000 series appliances. It installs into a modular expansion slot on these platforms.

Q: What is the difference between the CPAC-4-10/25F-DA and the CPAC-4-10/25F-D?
A: The CPAC-4-10/25F-DA includes hardware acceleration powered by Nvidia ASIC technology, enabling line-rate firewall throughput. The CPAC-4-10/25F-D is the non-accelerated variant. The accelerated card is visually identified by the word 'Acceleration' printed on its lower right corner.

Q: What transceivers and cables are supported?
A: The card supports Check Point-approved transceivers including CPAC-TR-10SR-D, CPAC-TR-10LR-D, CPAC-TR-10ER-D, CPAC-TR-25SR-D, and CPAC-TR-25LR-D. It also supports 25GBASE-CR1 SFP28 DAC cables up to 3 metres (SFF-8402 and SFF-8436 compliant).

Q: What minimum software version is required to use the CPAC-4-10/25F-DA?
A: The card requires a minimum of Check Point Gaia OS R81.20 with Jumbo Hotfix Accumulator Take #101, or R82 Take #36. Ensure your appliance is running a compatible software version before installation.

Q: Is the CPAC-4-10/25F-DA supported under Check Point Maestro?
A: Maestro support is not available at the time of release but is on the product roadmap for a future update. For Maestro-based deployments, consult Check Point's current compatibility documentation.

Q: Can I purchase the CPAC-4-10/25F-DA in Australia from IP Trading?
A: Yes. IP Trading (iptrading.com.au) is an Australian B2B IT hardware reseller stocking Check Point Quantum Force accessories and expansion modules. Contact us for pricing, availability, and advice on compatible transceivers or DAC cables for your deployment.
