Cambium Networks ANT-OM-1X1-05 | Tri-Band Omni Antenna, 2.4/5/6 GHz, 1x1, N-Male, 5 dBi

The ANT-OM-1X1-05 is a tri-band omnidirectional wireless antenna covering 2.4 GHz, 5 GHz, and 6 GHz, purpose-built for Cambium Networks XE3-4TN outdoor Wi-Fi 6E access points. With 360° omnidirectional coverage and a 1x1 antenna chain configuration, it delivers consistent signal radiation across all three bands — making it ideal for wide-area outdoor deployments where broad spectrum coverage is required. The N-type male connector ensures straightforward integration, and the ruggedised construction handles operating temperatures from -40°C to 85°C.

Peak gain reaches 4.4 dBi at 2.4 GHz and 5.5 dBi across both 5 GHz and 6 GHz bands, with linear polarisation and 50 Ω impedance maintained across all frequencies. Up to six of these antennas can be deployed per XE3-4TN access point, enabling scalable MIMO configurations. Order direct from iptrading.com.au — Australian-owned and operated since 2001.

- Tri-band support across 2.4 GHz, 5 GHz, and 6 GHz for broad Wi-Fi 6E spectrum compatibility
- Omnidirectional 360° radiation pattern for wide-area outdoor coverage
- 1x1 antenna chain configuration — up to 6 per XE3-4TN access point
- N-type male connector for direct, secure integration with Cambium outdoor APs
- Linear polarisation and 50 Ω impedance for consistent signal integrity across all bands
- Ruggedised design rated for extreme temperatures from -40°C to +85°C
- Designed specifically for Cambium Networks XE3-4TN outdoor Wi-Fi 6E access points
- Compact and lightweight at 75 g for easy pole or wall mounting

Cambium Networks offers a standard 1-year limited warranty on most hardware products, covering defects in materials and workmanship under normal use conditions.
Extended Warranty Periods for Specific Products:
Certain product families come with extended warranty periods:
• cnMatrix – EX Series: 5 years
• cnMatrix – TX Series: 3 years
• cnPilot Wi-Fi 5 E-Series Indoor Access Points: 5 years
• cnPilot Wi-Fi 5 E-Series Outdoor Access Points: 3 years
• ePMP, PMP 450 Series, PTP 450 and PTP 550 Series: 3 years
• Wi-Fi 6 Indoor Access Points (e.g., XE3-4, XE5-8, XV2-2): Limited Lifetime Warranty (valid through product End of Life)
• Wi-Fi 6 Outdoor Access Points (e.g., XV2-2T): 3 years
• Wi-Fi 7 Indoor Access Points (e.g., X7-35X): Limited Lifetime Warranty (valid through product End of Life)
• Xirrus Series (e.g., XR-1xxx, XR-2xxx): 5 years
• Xirrus Series (e.g., X2-120, XR-320): Limited Lifetime Warranty (valid through product End of Life)
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for Cambium Networks products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
