ATEN SN1132CO-AX-U | SN11xxCO 32-Port Serial Console Server, Dual Power, SFP

Name: ATEN SN1132CO-AX-U | SN11xxCO 32-Port Serial Console Server, Dual Power, SFP
Brand: ATEN
SKU: SN1132CO-AX-U
Price: 7368.09 AUD
Availability: BackOrder

Authorised ATEN Partner

SKU:SN1132CO-AX-U

Stock Status: Enquire

$7,368.09 inc. GST

$6,698.26 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The ATEN SN1132CO-AX-U is a 32-port serial console server that gives secure in-band and out-of-band access to serial and USB console devices. It combines dual AC power inputs with dual SFP LAN slots for failover, so remote access to network switches, routers and servers stays available if a power feed or uplink fails. This -AX-U variant ships with a US power cord. Auto-sensing DTE/DCE on the RJ-45 serial ports allows direct connection to Cisco network switches.

The unit includes sensor ports for environmental monitoring, a relay output, four USB Type A ports and a Mini USB laptop console port. Access is available through Telnet/SSH, Java viewer, ActiveX and WebClient, with TLS 1.2 encryption, RADIUS, TACACS+, LDAP/AD and Kerberos authentication. It integrates with CC2000 and CCVSR software and fits a 1U rack in a metal housing.

Features

- Secure in-band and out-of-band remote serial and USB console access
- Dual power supplies and dual SFP slots allow failover
- Auto-sensing DTE/DCE supports direct connection to Cisco network switches
- Access via Telnet/SSH, Java viewer, ActiveX and WebClient
- Up to 16 simultaneous connections per port
- TLS 1.2 encryption with RSA 2048-bit certificates, FIPS 140-2 level 1 supported
- Authentication via RADIUS, TACACS+, LDAP/AD and Kerberos, IEEE 802.1X compliant
- IP and MAC address filtering
- SNMP v1/v2c/v3, SMTP email and SNMP trap event notification
- IPv4/IPv6, LLDP and CLI support
- Sensor ports for environmental monitoring
- Integrates with CC2000 and CCVSR software
- Multi-language web GUI

Warranty

ATEN products sold by IP Trading are backed by a 24-month warranty against material defects and faulty workmanship from the date of shipment. Included accessories such as adapters and cables are covered for the same 24-month period, while batteries are covered by a 12-month warranty.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 32 x RJ-45 female serial ports
- 2 x SFP LAN slots
- 2 x IEC 60320/C14 power inputs, 100-240 VAC, 50/60 Hz
- Auto-sensing DTE/DCE for direct Cisco console connection
- 1 x RJ-45 local console port
- 1 x Mini USB laptop console port
- 4 x USB Type A female ports
- 2 x RJ11 and 1 x 4-pin terminal block environment sensor ports
- 1 x relay output, normally open, isolated, max 24 VDC, 2A
- Power consumption: 11.2W at 110 VAC, 11.3W at 220 VAC
- Operating temperature: 0 to 55 C
- Humidity: 0 to 80% RH, non-condensing
- Metal housing, 1U rackmount
- Dimensions (L x W x H): 43.84 x 32.84 x 4.40 cm
- Weight: 4.60 kg

FAQs

Q: How many devices can the SN1132CO-AX-U manage?
A: It has 32 RJ-45 serial ports, so it can provide console access to up to 32 serial devices, with up to 16 simultaneous connections per port.

Q: Does it provide redundancy?
A: Yes. It has two IEC 60320/C14 AC power inputs and two SFP LAN slots, allowing failover if a power feed or network uplink is lost.

Q: Can it connect directly to Cisco switches?
A: Yes. The serial ports use auto-sensing DTE/DCE, which allows direct connection to Cisco network switch console ports.

Q: Which authentication methods are supported?
A: It supports RADIUS, TACACS+, LDAP/AD and Kerberos authentication, is IEEE 802.1X compliant, and offers IP and MAC address filtering.

Q: Can it monitor the environment around the rack?
A: Yes. It has two RJ11 and one 4-pin terminal block sensor ports, plus a relay output, for environmental monitoring.

Q: Is it rack mountable?
A: Yes. It is a 1U rackmount unit in a metal housing.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
