ATEN PE0218SG-AT-G | 1U Basic Rack PDU, 18 Outlets, Surge Protection, 16A

Name: ATEN PE0218SG-AT-G | 1U Basic Rack PDU, 18 Outlets, Surge Protection, 16A
Brand: ATEN
SKU: PE0218SG-AT-G
Price: 226.44 AUD
Availability: BackOrder

Authorised ATEN Partner

SKU:PE0218SG-AT-G

Stock Status: Enquire

$226.44 inc. GST

$205.85 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The ATEN PE0218SG is a 1U rack-mount basic PDU with 18 outlets (17 x IEC C13 and 1 x IEC C19), a 16A IEC C20 input and built-in surge protection. It is suited to data centres, server rooms and network wiring closets where compact, reliable power distribution is needed for rack equipment.

The aluminium housing and overcurrent protection device help protect connected IT hardware from sudden power surges and overloads. With a 100-240VAC input range and support for up to 3840VA, it suits a wide range of servers, network switches and telecom equipment.

Features

- Space-saving 1U rack-mount design
- Surge protection shields connected IT devices from sudden power surges
- Overcurrent protection to reduce equipment downtime
- Durable aluminium housing
- Suitable for data centres, server rooms and telecom equipment
- 17 x C13 and 1 x C19 outlets for a mix of equipment types

Warranty

ATEN products sold by IP Trading are backed by a 24-month warranty against material defects and faulty workmanship from the date of shipment. Included accessories such as adapters and cables are covered for the same 24-month period, while batteries are covered by a 12-month warranty.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- 1U rack-mount form factor, aluminium housing
- 18 outlets: 17 x IEC 60320 C13 and 1 x IEC 60320 C19
- Nominal input voltage: 100-240 VAC, 50-60 Hz
- Input connection: IEC 60320 C20
- Maximum input current: 16A
- Maximum input power: 3840VA
- Maximum output current per outlet: C13 10A, C19 16A
- Overcurrent Protection Device (OPD): Yes
- Built-in surge protection module
- Package contents: 1 x PDU, 1 x power cord, 1 x user instructions

FAQs

Q: What outlet types does the PE0218SG provide?
A: It provides 18 outlets in total: 17 x IEC 60320 C13 and 1 x IEC 60320 C19.

Q: What input does this PDU require?
A: It uses an IEC 60320 C20 input connection with a nominal 100-240 VAC, 50-60 Hz supply and a maximum input current of 16A.

Q: Does the PE0218SG include surge protection?
A: Yes. It has a built-in surge protection module and an overcurrent protection device to help protect connected equipment.

Q: What is the maximum current per outlet?
A: Each C13 outlet supports up to 10A and the C19 outlet supports up to 16A.

Q: Is this a switched or metered PDU?
A: No. It is a basic PDU designed for straightforward power distribution without remote switching or metering.

Q: What is included in the box?
A: The package includes 1 x PDU, 1 x power cord and 1 x user instructions.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .
