Description

The ATEN PE0212G 1U Basic rack PDU delivers 12 IEC C13 outlets in a compact 1U aluminium housing, with a 100-240 VAC, 16A IEC-320 C20 input. Designed for servers, network devices and telecom equipment, it mounts vertically on the outside of the rack and includes an Overcurrent Protection Device (OPD) for added safety.

This is the IEC 16A model of the PE0212 series, rated up to 3840VA with a 10 ft (3x1.5mm2) power cord supplied. Each outlet supports up to 10A, with a total output of 16A, making it a straightforward way to distribute power to multiple IEC-powered devices in a rack.

Features

- Space-saving 1U design mounted vertically on the outside of a rack
- 12 IEC C13 outlets for servers, network devices and telecom equipment
- Built-in Overcurrent Protection Device (OPD)
- Durable aluminium construction
- Wide 100-240 VAC input range for global compatibility
- Package includes 1x Basic PDU, 1x power cord and user instructions

Warranty

ATEN products sold by IP Trading are backed by a 24-month warranty against material defects and faulty workmanship from the date of shipment. Included accessories such as adapters and cables are covered for the same 24-month period, while batteries are covered by a 12-month warranty.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- 12 x IEC 320 C13 outlets
- Input: IEC-320 C20, 100-240 VAC, 16A max, 50-60 Hz
- Input power: 3840VA max
- Maximum output current: 10A per outlet, 16A per bank, 16A total
- Overcurrent Protection Device (OPD)
- 1U rack mount design, aluminium construction
- Power cord: 10 ft (3x1.5mm2)
- Dimensions (L x W x H): 48.20 x 4.44 x 4.50 cm
- Weight: 0.63 kg
- Operating temperature: 0-40 C, storage: -20 to 60 C
- Safety verification: LVD, UL

FAQs

Q: How many outlets does the PE0212G have and what type are they?
A: It provides 12 IEC 320 C13 outlets, suitable for servers, switches and other equipment that use standard IEC C13 power cables.

Q: What input connection and power rating does this model use?
A: This model uses an IEC-320 C20 input rated for 100-240 VAC, 16A maximum at 50-60 Hz, with a maximum input power of 3840VA.

Q: Is this a metered or switched PDU?
A: No. The PE0212G is a Basic PDU that distributes power to its outlets, with an Overcurrent Protection Device (OPD) for safety but without remote monitoring or switching.

Q: How is the PDU mounted in the rack?
A: It is a 1U rack mount PDU designed to be mounted vertically on the outside of the rack, keeping the internal rack space free for equipment.

Q: What is the maximum current per outlet?
A: Each outlet supports up to 10A, while the total output across all outlets is limited to 16A.

Q: What is included in the box?
A: The package contains one Basic PDU, one 10 ft power cord and user instructions.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .
