ATEN PE0210SG-AT-G | Basic 1U Rack PDU, 10x C13, 16A, C20 Input, Surge Protection

Name: ATEN PE0210SG-AT-G | Basic 1U Rack PDU, 10x C13, 16A, C20 Input, Surge Protection
Brand: ATEN
SKU: PE0210SG-AT-G
Price: 197.34 AUD
Availability: BackOrder

Authorised ATEN Partner

SKU:PE0210SG-AT-G

Stock Status: Enquire

$197.34 inc. GST

$179.40 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The ATEN PE0210SG-AT-G is a 1U rack-mount basic PDU that distributes power to ten IEC C13 outlets from a single IEC-320 C20 input, rated at 16A and 100-240 VAC. This G plug variant suits data centres, server rooms and telecom racks where compact, dependable power distribution with built-in surge protection is needed.

An integrated surge protector with an LED status indicator guards connected equipment against power surges and spikes, while an over-current protection device adds a further layer of safety. The impact-resistant aluminium housing and space-saving 1U form factor make it a straightforward addition to standard 19-inch racks.

Features

- Space-saving 1U rack-mount design
- Ten IEC C13 outlets for servers and network equipment
- Integrated surge protector with LED status indicator
- Protects against damage from power surges and spikes
- Over-current protection device
- Impact-resistant aluminium housing
- Suited to data centres, server rooms and telecom equipment

Warranty

ATEN products sold by IP Trading are backed by a 24-month warranty against material defects and faulty workmanship from the date of shipment. Included accessories such as adapters and cables are covered for the same 24-month period, while batteries are covered by a 12-month warranty.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- 10 x IEC 320 C13 outlets
- Input connection: IEC-320 C20 (G plug version)
- Nominal input voltage: 100-240 VAC, 50-60 Hz
- Maximum input current: 16A
- Maximum input power: 3840VA
- Maximum output current: 10A per outlet, 16A per bank and in total
- Surge protection with LED indicator
- Over-current protection device (OPD)
- 1U rack-mount, aluminium housing
- Power cord length: 10ft (3 x 2.5mm2)
- Weight: 0.67 kg (1.48 lb)
- Operating temperature: 0 to 40 C (lower the load to 60% as temperature approaches 40 C)
- Storage temperature: -20 to 60 C
- Package contents: 1x Basic PDU, 1x power cord, 1x user instructions

FAQs

Q: What input connection does the PE0210SG-AT-G use?
A: This G plug version has an IEC-320 C20 input, rated at 16A and 100-240 VAC, 50-60 Hz.

Q: How many outlets does it provide and what type are they?
A: It provides ten IEC 320 C13 outlets, each rated up to 10A, with a total maximum output of 16A.

Q: Does this PDU include surge protection?
A: Yes. It has an integrated surge protector with an LED indicator, plus an over-current protection device.

Q: Is this a metered or switched PDU?
A: No. It is a basic PDU that distributes power only, without remote monitoring or outlet switching.

Q: What is the form factor and what is in the box?
A: It is a 1U rack-mount unit with an aluminium housing. The box contains the PDU, a power cord and user instructions.

Q: What is the operating temperature range?
A: It operates from 0 to 40 C. Lower the load to 60% as the temperature approaches 40 C.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .
