ATEN PE0118SG-AT-G | Basic 1U Rack PDU, 18x IEC C13, 10A, Surge Protection

Name: ATEN PE0118SG-AT-G | Basic 1U Rack PDU, 18x IEC C13, 10A, Surge Protection
Brand: ATEN
SKU: PE0118SG-AT-G
Price: 198.61 AUD
Availability: BackOrder

Authorised ATEN Partner

SKU:PE0118SG-AT-G

Stock Status: Enquire

$198.61 inc. GST

$180.55 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The ATEN PE0118SG is a 1U basic rack PDU with 18 IEC C13 outlets, 10A rating and built-in surge protection, designed to distribute power to servers, network gear and telecom equipment in data centres and server rooms. Its compact aluminium housing and overcurrent protection device make it a space-saving, dependable choice for racks that need a high outlet count on a single 1U footprint.

This is the IEC model of the PE0118S family, accepting 100-240 VAC at 50-60 Hz through an IEC 60320 C14 input. The built-in surge protection module helps shield connected IT equipment from sudden power surges, while the overcurrent protection design helps reduce equipment downtime.

Features

- Space-saving 1U rack-mount design
- 18 IEC C13 outlets for high-density power distribution
- Built-in surge protection module protects connected IT equipment from sudden surges
- Overcurrent protection design reduces equipment downtime
- Compact aluminium housing
- Suited to data centres, server rooms and telecom equipment

Warranty

ATEN products sold by IP Trading are backed by a 24-month warranty against material defects and faulty workmanship from the date of shipment. Included accessories such as adapters and cables are covered for the same 24-month period, while batteries are covered by a 12-month warranty.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- 18 x IEC 60320 C13 outlets
- Input connection: IEC 60320 C14
- Input voltage: 100-240 VAC, 50-60 Hz
- Maximum current: 10A
- Maximum input power: 2400VA
- Surge protection
- Overcurrent protection device (OPD)
- Form factor: 1U rack-mount
- Housing: aluminium, black
- Operating temperature: 0 to 40 C
- Storage temperature: -20 to 60 C
- Weight: 1.89 kg
- Package contents: 1 x PDU, 1 x power cord, 1 x user instructions

FAQs

Q: What outlet type does the PE0118SG use?
A: It provides 18 IEC 60320 C13 outlets. The PE0118SA is the NEMA 5-15R version of this PDU.

Q: Does this PDU include surge protection?
A: Yes. It has a built-in surge protection module to help protect connected IT equipment from sudden power surges.

Q: What is the maximum current rating?
A: The PDU is rated for 10A maximum, with a maximum input power of 2400VA.

Q: What input voltage does it accept?
A: It accepts 100-240 VAC at 50-60 Hz through an IEC 60320 C14 input connection.

Q: Is this a metered or switched PDU?
A: No. It is a basic PDU that distributes power to connected equipment, with surge protection and overcurrent protection but no remote monitoring or switching.

Q: How much rack space does it need?
A: It is a 1U rack-mount PDU in a compact aluminium housing.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .
