Aruba R8Q74A | 580 Series Outdoor AP Molex AC Power Connector Kit, M25

Name: Aruba R8Q74A | 580 Series Outdoor AP Molex AC Power Connector Kit, M25
Brand: Aruba
SKU: R8Q74A
Price: 146.35 AUD
Availability: BackOrder

Authorised Aruba Partner

SKU:R8Q74A

Stock Status: Enquire

$146.35 inc. GST

$133.05 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Aruba AP-AC-MLX is an outdoor-rated Molex AC power connector kit designed for field assembly of AC power cables on HPE Aruba 580 Series outdoor access points, including the AP-584, AP-585, and AP-587. Sold separately from the access point, it allows installers to select their own cable length on-site and terminate it with a weatherproof Molex AC connector — ideal for outdoor deployments where pre-terminated cables are impractical.

The kit includes an M25 cable gland with O-ring, gland body, seals, clip, and sealing nut, providing a secure, weatherproof seal rated for harsh outdoor environments. It supports UV-resistant, outdoor-rated three-wire AC cable (18 AWG) with an outer diameter of 6–12mm. Compatible across all regional variants of the Aruba 580 Series.

Features

- Enables field assembly of AC power cable for Aruba 580 Series outdoor APs — choose your own cable length
- Outdoor-rated weatherproof design suitable for harsh and exposed environments
- M25 cable gland with O-ring provides a secure, sealed connection against moisture ingress
- Supports UV-resistant, outdoor-rated 18 AWG three-wire AC cable
- Compatible across all regional variants of the Aruba AP-584, AP-585, and AP-587
- Sold separately for maximum installation flexibility

Warranty

Aruba Networking offers a Limited Lifetime Warranty on many of its hardware products, including select switches and access points. This warranty covers defects in materials and workmanship for the duration of the product's life, with support available for up to five years after the product's end-of-sale date.
Other Aruba products come with warranties ranging from 1 to 5 years, depending on the specific model. Warranty terms can vary based on the product category and model number.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Aruba Networking products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.hpe.com/psnow/doc/a00143138enw?jumpid=in_pdfviewer-psnow

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Compatible APs: HPE Aruba AP-584, AP-585, AP-587 (all regional variants: EG, IL, JP, RW, US)
- Connector type: Molex outdoor AC
- Cable gland size: M25
- Supported cable outer diameter: 6–12mm
- Supported inner wire diameter: ≤3.1mm
- Supported cable type: UV-resistant, outdoor-rated three-wire AC, 18 AWG
- Includes: M25 gland body, O-ring, seals, clip, and sealing nut
- UPC: 190017569611
- UNSPSC: 43222631

FAQs

Q: Which Aruba access points is the AP-AC-MLX compatible with?
A: The AP-AC-MLX is compatible with all regional variants of the HPE Aruba 580 Series outdoor access points: AP-584, AP-585, and AP-587 (EG, IL, JP, RW, and US variants).

Q: What is included in the AP-AC-MLX kit?
A: The kit includes a Molex outdoor AC connector and an M25 cable gland assembly comprising the gland body, O-ring, seals, clip, and sealing nut — everything required to field-terminate an outdoor-rated AC power cable.

Q: What cable specifications are required for use with this connector kit?
A: The kit supports UV-resistant, outdoor-rated three-wire AC cable (18 AWG) with an outer cable diameter of 6–12mm and individual inner wire diameter of ≤3.1mm.

Q: Why would I need the AP-AC-MLX instead of a pre-terminated cable?
A: The AP-AC-MLX is ideal for deployments where custom cable lengths are required or where cables must be routed through conduit before termination. It gives installers full flexibility to cut cable to the precise length needed on-site.

Q: Is the AP-AC-MLX included with the Aruba 580 Series access point?
A: No — the AP-AC-MLX is sold separately. The access point does not ship with a pre-terminated AC power cable, so this connector kit (or a compatible pre-made cable) must be ordered independently.

Q: Can I purchase the AP-AC-MLX in Australia through IP Trading?
A: Yes. IP Trading (iptrading.com.au) supplies genuine HPE Aruba accessories including the R8Q74A AP-AC-MLX for Australian businesses. Contact us for pricing, availability, and bulk order enquiries.
