Aruba Instant On

Aruba Instant On R8R45A#ABG | Instant On 1430 8-Port Gigabit Switch, Unmanaged, Non-PoE

Aruba Instant On R8R45A#ABG | Instant On 1430 8-Port Gigabit Switch, Unmanaged, Non-PoE

SKU:R8R45A#ABG

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Aruba Instant On 1430 is an unmanaged 8-port Gigabit switch designed for small businesses and home offices that need simple, reliable, zero-configuration connectivity. With true plug-and-play operation, a fan-less silent design, and 16 Gbps switching capacity, it delivers solid Gigabit performance without the complexity or cost of managed networking — ideal for desktop deployments, branch offices, and quiet work environments.

The 1430 8G supports QoS/DSCP prioritisation for voice and video traffic, IEEE 802.3az Energy Efficient Ethernet to reduce power consumption, and Auto MDI/MDI-X on all ports to eliminate cable compatibility issues. Flexible mounting options include table-top, wall, and under-table installation with included brackets. In stock and ready to ship from iptrading.com.au — order now for fast dispatch.

Features

- True plug-and-play — no configuration, software, or ongoing management required
- Fan-less chassis enables silent deployment in offices, retail spaces, and home environments
- QoS / DSCP support prioritises voice and video traffic for better call and conferencing quality
- Auto MDI/MDI-X on all ports — works with straight-through or crossover cables automatically
- Half/full-duplex auto-negotiation and flow control prevent packet loss at congested nodes
- IEEE 802.3az Energy Efficient Ethernet reduces power draw during low-traffic periods
- Spanning Tree Protocol (STP) support for loop prevention
- VoIP-ready with Class B certification for home office deployments
- Flexible mounting: table-top, wall mount (ports up or down), and under-table surface mounting
- Compliant with IEEE 802.3, 802.3u, 802.3i, 802.3z, 802.3ab, 802.1p, 802.3x, 802.3az

Warranty

• Access Points & Secure Gateways: 2-year warranty
• Instant On Switches: Limited lifetime warranty
• Transceivers & DACs: 3-year warranty
Extended Warranty Options:
Extended coverage is available via IP Trading. Contact us to tailor a plan to your Aruba Instant On deployment.
https://instant-on.hpe.com/files/FAQ_AIO_Warranty-Support-Services.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 8 x RJ-45 10/100/1000 Mbps Ports
- Switching Capacity: 16 Gbps
- Forwarding Rate: 11.90 Mpps
- Packet Buffer: 2.0 MB
- Memory: 128 KB EEPROM
- Latency (100 Mbps): 2.7 µs | Latency (1 Gbps): 1.8 µs
- No PoE
- Unmanaged Layer 2
- Fan-less Design (silent operation)
- External Power Adapter
- Operating Temperature: 0°C to 40°C
- Mounting: Table-top, wall, under-table (brackets included)

FAQs

Q: Is the Aruba Instant On 1430 8G switch managed or unmanaged?
A: The 1430 8G is a fully unmanaged switch. It requires no configuration, no software, and no ongoing administration — simply plug it in and it works immediately. It is not compatible with the Aruba Instant On mobile app.

Q: Does this switch support PoE (Power over Ethernet)?
A: No. The R8R45A is the non-PoE variant of the Instant On 1430 8-port switch. It does not supply power to connected devices. If you need PoE, consider the Aruba Instant On 1430 8G PoE variant instead.

Q: How noisy is the Aruba Instant On 1430 8G in operation?
A: The switch features a fan-less design, meaning it operates in complete silence. This makes it ideal for quiet environments such as open-plan offices, reception areas, home offices, and small meeting rooms.

Q: What mounting options are available for this switch?
A: The 1430 8G supports table-top placement, wall mounting (with ports facing up or down), and under-table surface mounting. Wall mounting brackets are included in the box.

Q: Can I purchase the Aruba Instant On 1430 8G (R8R45A) in Australia from IP Trading?
A: Yes. IP Trading (iptrading.com.au) stocks the R8R45A with the ABG (Australia/New Zealand) power cord and is ready for fast local dispatch. Orders are fulfilled from Australian inventory, supporting businesses across the country.

Q: Does the 1430 8G support QoS for voice and video traffic?
A: Yes. Despite being unmanaged, the switch includes QoS and DiffServ Code Point (DSCP) support, which automatically prioritises voice and video traffic to help maintain call quality in VoIP and video conferencing environments.
