Arista CCS-710XP-12TH-2S | CCS-710XP 12-Port Fanless PoE Switch, 2x SFP+, 4x 60W, 8x 30W
Arista CCS-710XP-12TH-2S | CCS-710XP 12-Port Fanless PoE Switch, 2x SFP+, 4x 60W, 8x 30W
Authorised Arista Partner
SKU:CCS-710XP-12TH-2S
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista CCS-710XP-12TH-2S is a 12-port fanless PoE switch for campus-edge deployments where space and noise matter. It provides 8 x 30W PoE and 4 x 60W PoE 10M-1GbE RJ45 ports, plus 2 x 1/10G SFP+ uplinks, all powered by a fixed internal 180W AC power supply. Silent operation makes it well suited to conference rooms, retail showrooms, broadcast control rooms and small enclosures.
The switch runs Arista EOS, the same software used across all Arista routing and switching products, and is managed through CloudVision. Its compact 269 x 43.5 x 254 mm chassis offers multiple mounting options and supports a wide range of Arista 1G and 10G pluggable optics and cables.
Features
Features
- Runs Arista EOS, the same software as all Arista routing and switching products
- Managed via CloudVision
- Fanless, silent operation for quiet and space-constrained environments
- Multiple mounting options
- Supports a wide range of Arista 1G and 10G pluggable optics and cables
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 8 x 10M-1GbE RJ45 ports at 30W PoE
- 4 x 10M-1GbE RJ45 ports at 60W PoE
- 2 x 1/10G SFP+ uplinks
- Fixed internal AC power supply rated at 180W
- Fanless design
- Dimensions: 269 x 43.5 x 254 mm
- Weight: 2.05 kg (4.51 lbs)
FAQs
Q: How many PoE ports does the CCS-710XP-12TH-2S have?
A: It has 12 PoE RJ45 ports: 8 ports delivering up to 30W each and 4 ports delivering up to 60W each.
Q: What uplink options does this switch provide?
A: It has 2 x 1/10G SFP+ uplink ports that accept a wide range of Arista 1G and 10G pluggable optics and cables.
Q: Is this switch silent in operation?
A: Yes. It uses a fanless design, making it suitable for conference rooms, retail showrooms and other noise-sensitive spaces.
Q: What software does it run and how is it managed?
A: It runs Arista EOS and is managed through CloudVision.
Q: What is the total power supply capacity?
A: The switch has a fixed internal AC power supply rated at 180W, which supplies both the switch and its PoE devices.
Q: What are the physical dimensions of the switch?
A: The chassis measures 269 x 43.5 x 254 mm and weighs 2.05 kg, with multiple mounting options available.
