APC SEP6127G | EasyPDU Basic 0U Vertical Rack PDU, 32A, 1-Phase, 7.4kW, 20×C13 & 4×C19

APC SEP6127G | EasyPDU Basic 0U Vertical Rack PDU, 32A, 1-Phase, 7.4kW, 20×C13 & 4×C19

SEP6127G

Stock Status: Enquire

$451.19 inc. GST
$410.17 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC EasyPDU Basic 0U Vertical Rack PDU delivers 230V single-phase power at 32A/7.4kW to 24 IEC 60320 outlets — 20×C13 for standard IT loads and 4×C19 for high-draw equipment — making it ideal for high-density server racks and data centre enclosures across Australian enterprise and colocation environments. Its ultra-lightweight aluminium housing reduces weight by up to 50% compared to the previous generation, while the IEC 60309 2P+E input connection and hydraulic-magnetic circuit breakers ensure robust, reliable power delivery at full load.

The toolless mounting kit and vertical 0U form factor allow the unit to be installed in the rear channel of any standard rack without consuming precious rack-unit space. With CE, TÜV, and RCM certifications, this PDU meets Australian and international compliance requirements for professional IT deployments. Upgrade your network with gear from iptrading.com.au — Australia's IT hardware specialists.

Features

- Vertical 0U rack-mounted design preserves valuable rack unit space
- High-capacity 32A / 7.4kW input for demanding IT and data centre applications
- 24 IEC 60320 outlets: 20×C13 for standard devices, 4×C19 for high-power equipment
- Hydraulic-magnetic circuit breakers provide reliable overcurrent protection
- Ultra-lightweight aluminium housing — up to 50% lighter than the previous generation
- Toolless mounting kit and vertical brackets included for fast installation
- Side-mounted, rear-channel installation for flexible rack integration
- IEC 60309 32A 2P+E industrial inlet for secure, high-current connection
- Supports 50/60 Hz mains frequency for global and Australian deployments
- RCM, CE, TÜV, and EAC certified for professional IT environments

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form Factor: 0U Vertical Rack Mount
- Phase: 1 Phase
- Input Voltage: 230V
- Input Current: 32A
- Load Capacity: 7.4kW (7,360 VA)
- Input Connection: IEC 60309 32A 2P+E
- Outlets: 20 × IEC 60320 C13, 4 × IEC 60320 C19 (24 total)
- Frequency: 50/60 Hz
- Operating Temperature: -5°C to +45°C
- Storage Temperature: -25°C to +65°C
- Relative Humidity: 5–95% (non-condensing)
- Operating Altitude: 0–3,048 m (10,000 ft)
- Net Weight: 3.58 kg
- Dimensions (H × W × D): 117.5 cm × 6.2 cm × 4.44 cm
- Input Cable Length: approx. 3 m (9.84 ft)
- Colour: Black
- Certifications: CE, TÜV, EAC, RCM

FAQs

Q: What is the maximum load this PDU can support?
A: The SEP6127G supports a maximum input current of 32A at 230V single-phase, delivering up to 7.4kW (7,360 VA) of total load capacity — suitable for high-density IT equipment in server racks and data centres.

Q: What outlet types are provided, and how are they distributed?
A: The PDU provides 24 IEC 60320 outlets: 20×C13 outlets for standard IT devices such as servers, switches, and storage appliances, and 4×C19 outlets for high-power equipment like blade chassis and high-draw servers.

Q: What input connector does this PDU use?
A: It uses an IEC 60309 32A 2P+E (blue industrial) inlet, which is standard for high-current rack PDU applications. Ensure your rack's power feed is provisioned with a compatible 32A IEC 60309 socket or whip.

Q: Does this PDU fit in a standard 19-inch rack without taking up rack units?
A: Yes. The 0U vertical form factor allows it to be mounted in the rear cable channel of a standard 19-inch rack, freeing up all rack units for active equipment. The toolless mounting kit and vertical brackets are included.

Q: Is this PDU certified for use in Australia?
A: Yes. The SEP6127G carries RCM (Regulatory Compliance Mark) certification along with CE and TÜV approvals, confirming compliance with Australian and New Zealand electromagnetic and safety standards.

Q: Can I purchase the APC SEP6127G in Australia through IP Trading?
A: Yes. iptrading.com.au stocks APC power distribution products and ships to businesses across Australia. Contact our team for volume pricing, compatibility advice, or to confirm lead times for this PDU.
