• APC AP7586 2U rack PDU extender with 5 blue outlets and coiled cable
1 1

APC

APC AP7586 | NetShelter Basic 2U Rack PDU Extender, 32A, 4x IEC 309-32

APC AP7586 | NetShelter Basic 2U Rack PDU Extender, 32A, 4x IEC 309-32

Authorised APC Partner

AP7586

Stock Status: Enquire

$1,403.64 inc. GST
$1,276.04 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC AP7586 is a NetShelter Basic 2U rack PDU extender that distributes 230V power from a single 32A hard-wired input to four IEC 309-32 (32A) outlets. It suits data centre and server room racks where industrial-style 32A outlets are needed, with a total load capacity of 7360VA. The 4 x IEC 309-32 outlet configuration distinguishes it from the AP7585, which provides IEC C19 outlets.

The basic (non-metered, non-switched) design keeps power distribution simple and reliable. Resettable circuit breakers allow quick recovery from overload events, and a single input feeds multiple pieces of equipment to save installation time and cost. It mounts in the bottom 2U of a NetShelter or any standard 19-inch rack, with brackets and an installation guide included.

Features

- Basic (non-metered, non-switched) rack power distribution
- Resettable circuit breakers for quick recovery from overload events
- Single input power source feeds multiple pieces of equipment, saving installation time and cost
- Rack-mountable in the bottom 2U of a NetShelter or any standard 19-inch rack
- Includes rack mounting brackets and installation guide

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

FAQs

APC Replacement Battery Finder

Technical Specifications

- Form factor: 2U rack-mount
- Output: 4 x IEC 60309 (IEC 309-32), 32A, 230V
- Nominal output voltage: 230V
- Maximum total current draw: 32A
- Load capacity: 7360VA (7.36kVA)
- Nominal input voltage: 200V / 208V / 230V
- Input frequency: 50/60 Hz
- Input connection: hard wire, 3-wire
- Power cord: 1 x 8.5 m (28 ft) adaptable cord, without plug
- Dimensions (H x W x D): 89 x 437 x 89 mm
- Net weight: 4.1 kg
- Colour: Black

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: What type of outlets does the AP7586 provide?
A: It provides four IEC 60309 (IEC 309-32) outlets rated at 32A, 230V. The sibling AP7585 provides four IEC C19 outlets instead.

Q: Does the AP7586 come with a plug on the input cord?
A: No. It has an 8.5 m adaptable input cord supplied without a plug, as the unit is hard-wired to the supply.

Q: Is this PDU metered or switched?
A: No. The AP7586 is a basic PDU, so it offers no metering or remote outlet switching. It provides simple power distribution with resettable circuit breakers.

Q: What is the maximum load the AP7586 can support?
A: The maximum total current draw is 32A at 230V, which equates to a load capacity of 7360VA (7.36kVA).

Q: What rack space does it need and what is included for mounting?
A: It occupies 2U in a NetShelter or any standard 19-inch rack. Rack mounting brackets and an installation guide are included.

Q: What input supply does the AP7586 accept?
A: It accepts a 200V, 208V or 230V nominal input at 50/60 Hz via a 3-wire hard-wired connection, with a maximum input current of 32A.
