Aruba J9828A | 5400R zl2 700W PoE+ Power Supply Module, 1x C13 Inlet

Name: Aruba J9828A | 5400R zl2 700W PoE+ Power Supply Module, 1x C13 Inlet
Brand: Aruba
SKU: J9828A
Price: 1832.78 AUD
Availability: BackOrder

Authorised Aruba Partner

SKU:J9828A

Stock Status: Enquire

$1,832.78 inc. GST

$1,666.16 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Aruba J9828A is a 700W PoE+ zl2 power supply module for the Aruba 5400R zl2 modular switch chassis, with a single C13 power inlet. It is an internal, hot-swappable module that supplies PoE+ power capacity to the chassis and supports redundant power configurations, making it well suited to campus and enterprise wiring closets built on 5406R and 5412R switches.

The module is supported in the 5406R (J9821A, JL002A, JL095A, JL003A) and 5412R (J9822A, JL001A) chassis. It can be mixed with 1100W and 2750W zl2 supplies in the same chassis, while full and N+1 redundancy require like supplies. A common zl2 form factor simplifies sparing across 5400R deployments.

Features

- Hot-swappable design allows replacement without interrupting the network when redundant supplies are installed
- Provides PoE+ (IEEE 802.3at, up to 30W per port) power capacity for chassis modules
- Supports redundant power for enhanced availability
- Can be mixed with other 5400R zl2 power supply ratings in the same chassis
- Common zl2 module simplifies sparing across 5400R chassis

Warranty

Aruba Networking offers a Limited Lifetime Warranty on many of its hardware products, including select switches and access points. This warranty covers defects in materials and workmanship for the duration of the product's life, with support available for up to five years after the product's end-of-sale date.
Other Aruba products come with warranties ranging from 1 to 5 years, depending on the specific model. Warranty terms can vary based on the product category and model number.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Aruba Networking products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.hpe.com/psnow/doc/a00143138enw?jumpid=in_pdfviewer-psnow

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 700W PoE+ power supply rating
- 1 x C13 power inlet
- Internal zl2 power supply module, hot-swappable
- Compatible with 5406R zl2 (J9821A, JL002A, JL095A, JL003A) and 5412R zl2 (J9822A, JL001A) chassis
- 5406R chassis: minimum 1, maximum 2 power supplies (2 slots)
- 5412R chassis: minimum 2, maximum 4 power supplies (4 slots)
- Chassis input voltage: 100-127 / 200-240 VAC, 50/60 Hz
- Chassis 80plus.org certification: Gold

FAQs

Q: Which switch chassis is the J9828A compatible with?
A: It is supported in the Aruba 5406R zl2 (J9821A, JL002A, JL095A, JL003A) and 5412R zl2 (J9822A, JL001A) chassis.

Q: Can I mix the J9828A with other power supply ratings?
A: Yes, it can be mixed with 1100W and 2750W zl2 power supplies in one chassis. Full and N+1 redundancy are supported only when like supplies are installed.

Q: How many power supplies does each chassis take?
A: The 5406R has 2 power supply slots (minimum 1, maximum 2). The 5412R has 4 slots (minimum 2, maximum 4).

Q: Is the power supply hot-swappable?
A: Yes, it is a hot-swappable internal module, so it can be replaced without interrupting the network when redundant supplies are installed.

Q: What power inlet does the J9828A use?
A: It has a single C13 power inlet.

Q: Does it support PoE+?
A: Yes, it is a 700W PoE+ supply providing power capacity for IEEE 802.3at devices of up to 30W per port.
