Arista PWR-3K-DC-RED | 7500N 3000W DC Power Supply, -48/-60V, Red Handle

Arista PWR-3K-DC-RED | 7500N 3000W DC Power Supply, -48/-60V, Red Handle

Authorised Arista Partner

PWR-3K-DC-RED

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Arista PWR-3K-DC-RED is a 3000 W DC-input power supply module for Arista 7500N Series modular switch chassis. It accepts -48 or -60 V DC nominal input through front-panel terminals and uses a red ejector handle for fitting and removal, making it suited to data centres and telecommunications sites running DC power plants.

This hot-swappable module is supported in the DCS-7504N, DCS-7508N, DCS-7512N and DCS-7516N chassis, with up to 4, 8, 12 and 20 power supplies respectively. It supports N+1 and redundant power configurations. When replacing a failed unit, use the same PSU model and avoid mixing PSU types within a chassis.

Features

- Hot-swappable modular power supply with ejector handle
- Supports N+1 or redundant power configurations in 7500N chassis
- Front-panel status LED for at-a-glance power status
- Dedicated -48V, RTN and ground terminals for DC cabling
- Replace a failed unit with the same PSU model and avoid mixing PSU types

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Maximum DC output power: 3000 W
- Nominal input voltage: -48 or -60 V DC
- Maximum input current: 80 A
- Input branch circuit protection: 100 A
- DC input wire size: 2 - 4 AWG (33.6 mm2 to 21.2 mm2), stranded copper
- Primary ground wire size: 2 - 4 AWG (33.6 mm2 to 21.2 mm2) per power supply
- Front-panel terminals: -48V, RTN and ground
- Indicator: status LED
- Mechanical: ejector handle
- Supported chassis: DCS-7504N, DCS-7508N, DCS-7512N, DCS-7516N
- Maximum PSUs per chassis: 4 (7504N), 8 (7508N), 12 (7512N), 20 (7516N)

FAQs

Q: Which Arista chassis is the PWR-3K-DC-RED compatible with?
A: It is supported in the Arista 7500N Series chassis: DCS-7504N, DCS-7508N, DCS-7512N and DCS-7516N.

Q: What input voltage does this power supply require?
A: It is a DC-input module with a nominal input of -48 or -60 V DC, delivering up to 3000 W maximum output.

Q: Can it be replaced while the switch is running?
A: Yes, the module is hot-swappable and has an ejector handle. Replace a failed unit with the same PSU model and avoid mixing PSU types.

Q: How many power supplies can each chassis hold?
A: Up to 4 in the DCS-7504N, 8 in the DCS-7508N, 12 in the DCS-7512N and 20 in the DCS-7516N.

Q: What cabling is needed for the DC input?
A: Use stranded copper wire of 2 - 4 AWG for the DC input and for the primary ground, connected to the front-panel -48V, RTN and ground terminals. The input branch circuit should be protected at 100 A.

Q: Is redundant power supported?
A: Yes, the module supports N+1 or redundant power configurations within a 7500N chassis.
