Yealink ZVCS98-C5U-000 | ZVC S98 Zoom Rooms Kit, MCore 4, 3x SmartVision 80, AVHub

Authorised Yealink Partner

SKU:ZVCS98-C5U-000

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Yealink ZVC S98 Zoom Rooms kit is a complete Zoom Rooms on Windows video conferencing system for extra-large meeting rooms. This configuration pairs an MCore 4 mini-PC (Intel Ultra5 125H, 16GB DDR5, 256GB SSD) with three four-lens SmartVision 80 cameras, an MTouch Plus 11.6-inch touch controller, an AVHub processor, an RCH40 E2 PoE+ switch, a RoomSensor and the MVC-BYOD-Extender.

Each SmartVision 80 combines a 20x optical zoom PTZ lens with a panoramic lens and two telephoto lenses, with tracking modes including IntelliFocus, Presenter Tracking, Speaker Tracking and Auto Framing. The AVHub coordinates up to 9 Yealink cameras, and multiple kits can be linked to build dividable and mergeable rooms. The system ships with Windows 11 IoT Enterprise, the Zoom Rooms App and Yealink RoomConnect preloaded.

Features

- Four-lens SmartVision 80 cameras with PTZ, panoramic and dual telephoto lenses
- AI tracking: IntelliFocus, Presenter Tracking, Speaker Tracking and Auto Framing
- AVHub multi-camera processing for up to 9 Yealink cameras with customisable layouts
- Link multiple kits over network cables for dividable and mergeable rooms
- Wired USB-C/HDMI content sharing via MTouch Plus, and wireless sharing with the Yealink WPP30 dongle
- 4K auxiliary stream input via MCore 4 HDMI-In
- Single CAT5e cable carries data and power between MCore 4 and MTouch Plus
- RoomSensor reports room occupancy, temperature and humidity
- Remote management through Yealink Device Management Platform and Cloud Service

Warranty

Yealink offers a 36-month limited hardware warranty on most devices, including SIP phones, video conferencing systems, Teams-certified hardware, and headsets. This warranty covers defects in materials and workmanship from the date of purchase.
Extended Warranty Options:
IP Trading can provide extended warranty solutions for Yealink products—up to 5.5 years total coverage. Contact us to customise a plan that suits your deployment.
https://www.yealink.com/website-service/attachment/library-file/documents/20230920/20230920021310144a2ab989c4cafa71e0ab9cc4478ef.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 3 x SmartVision 80 four-lens cameras: 20x optical zoom PTZ, panoramic and 2 telephoto lenses
- MCore 4 Gen-4 mini-PC: Intel Ultra5 125H, 16GB (2x8GB) DDR5, 256GB SSD
- Preloaded Windows 11 IoT Enterprise, Zoom Rooms App and Yealink RoomConnect
- MCore 4 wireless: WiFi 802.11 a/b/g/n/ac/ax and Bluetooth 5.2
- MCore 4 interfaces: 1 x HDMI-Out 2.1, 2 x HDMI-Out 2.0, 1 x HDMI-In, 4 x USB 3.0 Type-A, 1 x Gigabit Ethernet
- MTouch Plus controller: 11.6-inch narrow bezel IPS touchscreen, 1920 x 1080
- AVHub: 7 x VCH ports, supports up to 9 Yealink cameras
- RCH40 E2 PoE+ switch: 4 x Gigabit ports, 90W total PoE budget (30W per port)
- SmartVision 80 PTZ lens: 20x optical zoom, 69 degree DFOV
- SmartVision 80 panoramic lens: 110 degree DFOV
- RoomSensor: occupancy, temperature and humidity detection, 120 degree detection angle
- Includes MVC-BYOD-Extender

FAQs

Q: What size of meeting room is this kit designed for?
A: The ZVC S98 is designed for extra-large meeting rooms. Three SmartVision 80 cameras provide PTZ, panoramic and telephoto coverage across the room.

Q: Does this kit run Zoom Rooms natively?
A: Yes. The MCore 4 mini-PC ships with Windows 11 IoT Enterprise, the Zoom Rooms App and Yealink RoomConnect preloaded.

Q: How many cameras can the AVHub support?
A: The AVHub supports up to 9 Yealink cameras. This kit includes three SmartVision 80 cameras.

Q: Can I share content wirelessly in the room?
A: Yes. Wireless sharing at 1080p/30fps is available with the Yealink WPP30 dongle, and wired sharing is supported via USB-C or HDMI on the MTouch Plus.

Q: What does the RCH40 E2 switch provide?
A: It is a 4-port Gigabit PoE+ switch with a 90W total PoE budget (30W per port) for powering room devices over the network.

Q: Can multiple rooms be combined with this kit?
A: Yes. Multiple kits can be linked over network cables to create dividable and mergeable rooms, with the AVHub supporting intelligent multi-speaker tracking.
