Ubiquiti POE-24-12W-G-WH-AU | 24V Gigabit PoE Injector, 12W, White, AU Plug

Ubiquiti POE-24-12W-G-WH-AU | 24V Gigabit PoE Injector, 12W, White, AU Plug

Authorised Ubiquiti Partner

SKU:POE-24-12W-G-WH-AU

$31.05 inc. GST
$28.23 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

In stock: 85

Description

The Ubiquiti POE-24-12W-G-WH-AU is a 24V passive PoE injector delivering 12W (24V DC at 0.5A) over a Gigabit RJ45 port, powering compatible Ubiquiti airMAX, airFiber, UniFi and mFi devices through a single Ethernet cable. This is the white version supplied with an Australian (AU) mains plug cable, ready for local deployment.

The injector accepts a universal 100-240V AC input and includes surge and clamping protection, plus an earthed AC cable. A built-in reset button supports remote reset of the powered device, helping reduce site visits for outdoor and hard-to-reach installations.

Features

- Powers Ubiquiti airFiber, airMAX, airVision, UniFi and mFi PoE devices
- Gigabit LAN port for full-speed data alongside power
- Surge and clamping protection
- Maximum surge discharge and peak pulse current protection
- Earthed AC cable
- Remote reset capability via reset button
- Universal 100-240V AC input

Warranty

Ubiquiti products come with a 1-year limited hardware warranty covering defects in materials and workmanship under normal use.

Extended Warranty Options:
Extended warranty options may be available through IP Trading. Contact our team to discuss coverage tailored to your needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Output: 24V DC at 0.5A (12W)
- 1 x Gigabit RJ45 Data IN / PoE port
- Input: 100-240V AC, 50/60 Hz
- Passive PoE, 2-pair powering (pins 4, 5 positive; pins 7, 8 negative)
- Remote reset capability with reset button
- Colour: White, AU plug
- Dimensions: 87 x 44 x 29 mm
- Weight: 99 g
- Operating temperature: 0 to 40 C
- Operating humidity: 35 to 95% non-condensing
- Storage temperature: -30 to 70 C

FAQs

Q: What output does this PoE injector provide?
A: It provides 24V DC at 0.5A, a total of 12W, using passive 2-pair PoE on pins 4, 5 (positive) and pins 7, 8 (negative).

Q: Does this injector support Gigabit speeds?
A: Yes. It has a Gigabit RJ45 Data IN / PoE port, so network data passes through at Gigabit speeds while power is injected.

Q: Is this injector compatible with 802.3af/at PoE devices?
A: No. This is a 24V passive PoE injector intended for Ubiquiti devices that use 24V passive PoE, such as airMAX, airFiber, UniFi and mFi products. Confirm your device accepts 24V passive PoE before connecting.

Q: Does it come with an Australian power cable?
A: Yes. This SKU is the white version supplied with an AU plug AC cable that includes earth ground.

Q: Can I reset the connected device remotely?
A: Yes. The injector has a reset button and supports remote reset capability for the powered device.

Q: What input voltage does the injector accept?
A: It accepts 100-240V AC at 50/60 Hz, suitable for Australian mains supply.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
